Functions
Throttle REV
Steering REV
TH dual rate
ST dual rate
Throttle trim
Steering
trim
Power
Grip handle
Battery box
Version Reflex Wheel Pro
For use in France the switch must
Version Reflex Wheel Pro2
"Fail safe Pro + SET"
For use in France the switch must
be set to "F"/"Fra".
CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
Steering
wheel
Throttle
trigger
Switch
"France" switch
be set to "F"/"Fra".
Fail safe set
Switch
"France" switch
2,4 GHz Antenne
Throttle
rate adjuster
Throttle trigger
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
Batt: Power connector
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
5. Channel 5 servo (CH 5)
BEC: Power connector for
BEC use
"France" switch
For use in France the
switch must be set to
"F"/"Fra".
Charger
socket
