The transmitter requires 4 conventional or
rechargeable AA (Mignon) batteries for operation.
Once you switch on the On/Off switch, the
transmitter is ready for use.
After the transmitter has been switched on, the
battery voltage will appear in "V" on the LCD
display and, below it, the model name/number last
selected will be displayed.
Settings are changed by means of the "SEL", "CH",
"+" and "-" buttons.
1. Press +/- to select the desired model. You have
the choice of 15 memory spaces. The model
number and model name are indicated on the
LCD display.
2. Press "SET" to take you to the desired setting. The
following functions are available for selection:
• "REV" setting (reverse direction of servo rotation)
Press the "CH" button and choose between ST,
TH or 3CH. Press +/- for normal or reverse.
• "EPA" setting (servo travel limiter)
Press the "CH" button and choose between TH or
ST. To select the direction of rotation, the throttle
must be to the front or back with TH, and the
steering wheel must be moved left or right with
ST. The display shows LFU for left and forwards
and RBU for right and brake. The desired value
can be set between 0 and 120% by means of +/-.
• ABS setting (anti-blocking system)
Press +/- for ABS on or ABS off.
• EXP setting (exponential)
Press the "CH" button and choose between ST
(steering), FW (forwards) and BK (brake). The
desired exponential value can be set between
-100% and 100% by means of +/-.
• MODEL NAME (enter name of model)
Press the CH button until you come to the model
name setting. The characters 0 - 9 and A - Z can
be entered by means of +/-.
CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
3. ST-TRIM (trimming the steering)
Press TRIM-ST+ or TRIM-ST- to change the neutral
position of the steering servo.
It may be adjusted from 0 - 100% right to
0 - 100% left.
4. TH-TRIMM (trimming the throttle)
Press TRIM-TH+ or TRIM-TH- to change the
neutral position of the throttle servo.
It may be adjusted from 0 -100% throttle to
0 - 100% brake.
5. D/R ST setting (dual rate steering)
Dual rate increases or reduces the servo travel
in relation to the travel of the steering wheel/
throttle proportionally over the entire servo path.
Press D/R ST+ or D/R ST- to change the dual rate
setting of the steering.
A value between 0 and100% may be set.
6. D/R TH setting (dual rate throttle)
Press D/R TH+ or D/R TH- to change the dual rate
setting of the throttle.
A value between 0 and 100% may be set.
7. To close the settings, press the SEL button until
the battery display reappears.
Then the newly entered values are automatically
saved.
