Functions

LCD display
GB
+/- button
SEL/CH
button
ST D/R
button
TH D/R
button
Power switch
Grip handle
Battery box
Version Reflex Wheel Pro LCD
For use in France the switch must
Version Reflex Wheel Pro2 LCD
For use in France the switch must
34 CARSON Reflex Wheel Pro 50 050 0034 + 35 + 36 + 37
Steering trim
Throttle trim
Throttle
trigger
Switch
"France" switch
be set to "F"/"Fra".
Fail safe set
Switch
"Failsafe Pro + SET"
"France" switch
be set to "F"/"Fra".
2.4 GHz antenna
Steering wheel
"France" switch
Throttle rate
adjuster
Switch for
3rd channel
For use in France the switch
must be set to "F"/"Fra".
Charger
socket
Connectors:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
Batt: Power connector
Steckplätze:
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. Channel 3 servo (CH3)
4. Channel 4 servo (CH4)
5. Channel 5 servo (CH 5)
BEC: Power connector or
BEC use
