6.4 Changing the saw blade (Fig. 1/7-8)
Danger! Always pull out the power plug befo-
re doing any work on the circular saw!
Use only saw blades which comply with standard
EN 847-1 and are of the same type as the saw
blade supplied with this circular saw. Ask your
dealer for advice.
Caution! The mini hand-held circular saw must
not be operated with the Allen key inserted in it.
•
Undo the screw for securing the saw blade
(12) by turning it in clockwise direction with
the Allen key (a) while at the same time hol-
ding on the opposite side with the Allen key
(b).
•
Press the locking button (3) and use the lever
(5) to raise the adjustable soleplate (6) and
hold.
•
Remove the saw blade (7) in a downwards
direction.
•
Clean the flange and insert the new saw bla-
de. Pay attention to the running direction (see
arrow on the housing (c) and saw blade).
•
Tighten the screw to secure the saw blade
(12), check it runs true.
•
Before you press the On/Off switch, make
sure that the saw blade is correctly fitted and
that moving parts run smoothly and the clam-
ping screws are tightened securely.
6.5 Replacing the drive belt (Fig. 9-10)
•
The belt should be replaced by a trained ex-
pert.
•
The drive belt (B) must be replaced if it is
worn.
•
Undo the screw (a) and remove side belt co-
ver (A).
•
Unscrew the screw from the belt pulley (C)
and remove the disk from on top of the belt
pulley.
•
Remove the worn drive belt (B) and clean the
two belt pulleys (C/D).
•
Place the new drive belt on the belt pulley (C)
and pull the belt onto the belt pulley (D) whilst
turning the shaft.
•
Make sure that the drive belt is properly sea-
ted on the belt pulleys.
•
Place the disk back on the belt pulley (C) and
secure it with the screw.
•
Fit the belt cover (A) and secure it with the
screw (a).
Anl_TC_CS_860_Kit_SPK7.indb 19 Anl_TC_CS_860_Kit_SPK7.indb 19
GB
6.6 Reset button (Fig. 11)
In case of overloading, e.g. due to the saw blade
becoming jammed, the equipment will shut down
automatically. To restart, you must fi rst press the
reset button (14). The equipment can then be
operated as normal.

7. Replacing the power cable

Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
8. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
8.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualifi ed electrician.
Danger! The carbon brushes should not be rep
laced by anyone but a qualifi ed electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
- 19 -
