Addressing
Press the MODE button until the display shows DMX MODE.
Press the ENTER button and the display shows: 001.
As soon as the digits blink, you can select the desired values via the UP or DOWN buttons.
Please press the ENTER button again to confirm and to select a DMX Channel Mode.
Controlling:
After having addressed the device, you may now start operating it via your lighting controller.
Note: It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order
to ensure proper transmission on the DMX data link.
DMX Channel Selection: Choosing a DMX Channel Mode up to 7 Channel Occupation
After having set the desired addresses and pressed ENTER, you can now choose a DMX Channel Mode.
(4 CH, 6 CH, 7 CH).
Set the desired mode via the UP or DOWN buttons.
Press the ENTER button again to confirm and to exit the DMX Mode.
Please see the following DMX protocol graphics for the respective channel values.
DMX-Protocol
4-channel mode:
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
Channel:
Value:
3
000 – 255
Channel:
Value:
4
000 – 255
6-channel mode:
Channel:
Value:
1
000 – 255
Channel:
Value:
2
000 – 255
Channel:
Value:
3
000 – 255
Channel:
Value:
4
000 – 255
Channel:
Value:
5
000 – 255
Channel:
Value:
000 – 000
001 – 005
6
006 – 010
011 – 255
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
Function:
White (0 – 100%)
Function:
Red (0 – 100%)
Function:
Green (0 – 100%)
Function:
Blue (0 – 100%)
Function:
White (0 – 100%)
Function:
Dimmer (0 – 100%)
Function:
Neutral
Off
Neutral
Strobe (increasing)
25/32
00069276.DOC, Version 1.0
