Dear MAGNAT Customer,
The PANTERA ONE car hi-fi power amplifier will enable you to satisfy your high demands on sound reproduction
in your car. With its impressive deep-bass power reserves, low harmonic content and neutral reproduction, the
PANTERA ONE takes car hi-fi to new heights. The amplifier is characterized by low operating current, rapid
switching capabilities and excellent temperature stability. Experience and enjoy how this high-tech machine
perfectly reproduces magnificent sound.
Magnat Audio-Produkte GmbH
Please read all of the owner's manual before installing and using the amplifier.
1. TECHNICAL DATA
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 342, B+=14.4V)
Loudspeaker impedance
Frequency response
Total harmonic content (DIN 45 403)
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Low-pass filter
Bass boost
Supply
Fuse
Sizes (W x H x D)
Weight
SUBJECT TO TECHNICAL CHANGE
2. FEATURES
· Complementary push-pull final stage
· Stable at 2 ohms
· Infinitely variable low-pass filter
· Infinitely variable bass equalisation
· Adjustable input sensitivity
· Electronic protective circuit against short circuiting, DC offset and excess temperature
· Mute switch for suppressing switch-on crackle interference
· Low-level outputs (cinch jacks) for connecting additional amplifiers
· Capsulated loudspeaker and power-supply screw terminals
· Status indicator (green LED) and overload indicator (red LED)
· Remote control for volume control
3. IMPORTANT INSTALLATION INFORMATION
· This appliance may only be connected to a 12 volt system with negative ground.
· The heat radiated when the amplifier is used means that sufficient air circulation is required at the place
of installation. It is very important that the cooler's cooler ribs do not contact any metal plating or any
surfaces which could impair air circulation. The amplifier may not be installed in small confined spaces or
spaces without air circulation (e.g. spare wheel recess or under the vehicle carpeting). Installation in the
boot is recommended.
GB
PANTERA ONE
600 W on 4 Ohm
300 W on 4 Ohm
1000 W on 2 Ohm
450 W on 2 Ohm
2 – 8 Ohm
5 – 90 000 Hz (-3 dB)
< 0.03 % (1 kHz)
> 105 dB
0.4 – 4 V
47 kOhm
40 – 250 Hz, 12 dB per octave
0...12 dB at 45 Hz
+12 V (10 – 15 V), minus to ground
2 x 35 A
395 x 65 x 280 mm
5 kg
