Sealed battery
To charge a sealed battery, it is necessary to be extremely careful. The charge must be applied slowly whilst constantly
monitoring the battery voltage. It is recommended to stop the charge when the voltage (voltage charging court) reaches
14.4V for a 12V battery and 28.8V for a 24V battery. This voltage can be measured using a voltmeter or battery tester.
Charge
Once the charger is connected to the battery as recommended (see connection and disconnection),
For the START 200 and 300:
- Turn the switch to the CHARGE or BOOST 1 position according to the battery capacity.
Warning : In Boost 1 mode thermal protection might be activated at the beginning of the charge if the battery is deeply
discharged.
After use follow the recommended instructions for disconnection.
Charging multiple batteries simultaneously
You can charge multiple batteries simultaneously connecting them in parallel. Connect the positive terminals to the red
clamp and the negative terminals to the black clamp. These batteries or group of batteries must all be the same voltage,
12 or 24V.
Charging in series is not recommended.
USE IN STARTING MODE
Precautions before use
• Do not disconnect the battery from the vehicle. Disconnecting the battery may result in loss of information and a
possible inability to restart.
Starting
Once you have connected the starter to the battery as recommended (see connection), it may be necessary to precharge
the battery to provide the energy needed for starting. To perform a precharge turn the switch on the "BOOST " position.
Start 200
Start 300
To perform the precharge set the switch to the "BOOST" position.
To start a vehicle turn the switch to the "START" position. Go to the vehicle driver side. By turning the key you activate
the starter function. This function must be stopped as soon the vehicle start. It is ideal to work with two people. The
one close to the START can turn the switch to the START position at the last moment and stops the device once the
vehicle has started.
If your engine does not start, wait 2 minutes between two start attempts. The attempt must last a maximum of 3 sec.
Nb: A vehicle that will not start can be a problem other than a battery in poor condition. It could come from many other
causes.
After use follow the recommended instructions for disconnection.
START 200 / 300
Start 200
Start 300
START 200 and 300 :
Instantaneously
35 - 40 Ah
35 - 50 Ah
CHARGE (12-24V)
53 - 240 Ah (11A)
38 - 300Ah (10A)
5 min precharge
40 - 80 Ah
50 - 100 Ah
