FUNCTIONAL DESCRIPTION OF CONTROLS:

Solution Tank Fill (1) – Open to fill the solution tank, use non-foaming chemicals only (capacity 20 gal. / 75 liters)
Recovery Tank Cover (2) – Point of entry for waste water into tank. Also houses float ball which shuts off vacuum port to vac motor when tank is full.
Squeegee Lever (3) – This lever controls both the squeegee and the vacuum motor. There are three positions: OFF, vacuum ON and vacuum ON with the
squeegee on the floor.
* Off
* Vacuum ON
This position lifts the squeegee slightly while leaving the vacuum turned on. This can be used for backing up during scrubbing, or supplies vacuum
for cleaning remote areas using an attachment.
* Vacuum ON with the squeegee on the floor
This position is for picking up solution while scrubbing.
Brush Raise / Lower Pedal (4) – Located at the right rear corner near the floor, this pedal is used to raise or lower the brush head.
Drive Paddle (5) – Located on top at the rear of the machine, the operator can make the machine go forward by pushing forward on it, or reverse by pulling
backward on it. The speed is variable depending on how far forward or backward the padel is moved. When the brush head is in the "DOWN" position, the
brushes and solution will operate when the drive is engaged in either direction, but will stop after the machine is stationary for 1 second.
Solution Drain Hose / Level Indicator (6) – Used to empty the solution tank and show current level of solution in tank, graduations are marked on the side
of the solution tank next to the hose.
Recovery Drain Hose (7) – Used to empty the recovery tank.
Squeegee Adjustment Knob (8) – Used to adjust the tilt of the squeegee. Turn knob clockwise to tilt the squeegee backwards and counter-clockwise to tilt
it forward.
Squeegee Blade Latch (9) – Holds rear squeegee blade and straps in place, release to replace rear blade.
Squeegee (10) – Picks up solution after scrubbing.
Machine Battery Connector (11) – Batteries plug into this connector, disconnect to charge batteries.
Battery Fuel Gauge (12) – Shows current state of charge of batteries.
Hour Meter (optional) (13) – Displays number of hours machine has been used.
Solution Switch (14) – This switch is used to select the mode of operation for the solution system. There are 3 modes of operation for this system. The modes
are OFF, ON, MOMENTARY ON. Following is a description of each mode and how they are selected.
OFF: In this mode the solution flow is turned off.
ON: In this mode the solution flow will be turned on whenever the Drive Paddle (5) is in forward or reverse mode. The solution flow will be turned off otherwise.
MOMENTARY ON: Solution can be dispensed by pressing and holding the solution button. Solution will be dispensed for as long as the button is held. This
is for pre-wetting the floor prior to scrubbing.
Brush Remove Switch (15) – To remove the brush(es) from the machine, have the machine stationary and the Brush Deck (24) in the "RAISED" position. Press
the switch to the "REMOVE" position and release. The switch will snap to the OFF position, and the brush(es) will drop to the floor.
Solution Flow Control Knob (16) – Turn this dial to the right to increase solution flow to the floor. Turn to the left, to decrease the amount of solution flow to
the floor. When the Drive Paddle (5) is released from either forward or reverse travel, the solution flow will stop automatically, and resume when the drive is
engaged.
Speed Limit Control Knob (17) – The Speed Limit Control Knob is used to adjust the maximum speed in both forward or reverse.
Master Key Switch (18) – The master power switch.
Auxiliary Circuit Breaker (19) – Provides overload protection. If it trips, it will pop out. To reset, wait one minute and press the button back in. If any breaker
trips repeatedly, have the machine serviced.
Vacuum Motor Circuit Breaker (20) – Provides overload protection to machine's vacuum motor. If it trips, it will pop out. To reset, wait one minute and press
the button back in. If any breaker trips repeatedly, have the machine serviced.
Brush Motor Circuit Breaker (21) – Provides overload protection to machine's brush motor. If it trips, it will pop out. To reset, wait one minute and press the
button back in. If any breaker trips repeatedly, have the machine serviced.
Wheel Drive Circuit Breaker (22) – Provides overload protection to machine's wheel drive motor. If it trips, it will pop out. To reset, wait one minute and press
the button back in. If any breaker trips repeatedly, have the machine serviced.
Scrub Pressure Lever (23) – Two position lever provides two different scrubbing pressures.
TOP POSITION: In this position the full weight of the scrub deck rests on the floor.
BOTTOM POSITION: In this position the scrub pressure is approximately 30 pounds less.
Brush Deck (24) – Contains brush drive motor(s) and brush(es).
Operator Control Handle (25) – Operator holds onto this to control the machine.
14 - FORM NO. 56041527 - ConvertaMAX ™ 20, 26 / BA 550, BA 650
