Maxxus RX 6.1 Montageanleitung Und Bedienungsanleitung Seite 25

Teileliste
Teile-Nr. Beschreibung
75 plastic cap M10
76 nylon nut M10
77 flat washer M10
78 plastic spacer
79 hex head bolt M10x130
80 hex head bolt M10x70
81 round head screw M5x12
82 air flow adjuster
83 round head screw M5x15
84 monitor
85 across head screw M4x10
86 handlebar plug
87 screw M5x12.5mm
88 air flow adjuster clicker
89 machine screw M4x25
90 across head screw M6x12
91 pulley bracket
92 screw M5x20
93 aluminum patch
94 square magnet
95 one way bearing
96 bearing holder
97 Iron bush
98 adjust washer
99 clip
100 adjust washer
101 round head screw M4x25
102 magnet 15x7
103 plastic disc
104 spring washer M8
105 velcro elastic band
106 flat head phillip screw
107 allen head bolt M10x20
108 nylon nut
109 pin 10x148
110 allen head bolt M8x25
111 allen head bolt M10x25
112 screw M5x8
113 foot plate strap
Menge Teile-Nr. Beschreibung
2 114 spring washer M10
8 115 rear joining bracket
16 116 lock cap nut
4 117 allen head bolt M8X15
1 118 spring
1 119 sensor bracket
19 120 sensor bracket
1 121 rowing rail bracket
12 122 nut M8
1 123 hex head bolt M8x85
2 124 rear stabilizer xer
1 125 flat washer
14 126 phillip screw M5x15
1 127 plug 12
6 128 plug 15
4 129 monitor wire
1 130 monitor wire
6 131 sensor
1 132 fan
12 133L/R air fan cover (left/right)
1 134 middle air fan cover
1 135 flat head screw
1 136 knob
3 137 flat washer
1 138 curve washer M10
8 139 flat washer
2 140 curve washer M8
1 141 flat washer
1 142 screw M4x10
5 143 machine screw M4x15
2 144 plastic disc
3 145 nylon nut M6
2 146 foam
16 147 round head screw
1 148 washer 20x10x1.5
2 149 adjust knob M8x28
6 150 Ipad holder
3 151 countersunk screw M5x20
1p 152 round head screw M5x20
25
Menge
12
1
3
5
3
1
1
2
3
1
2
8
15
3
2
1
1
1
1
1
1
8
1
2
1
1
1
1
2
1
1
4
1
4
1
2
1
2
4
