Kröber O2-4.0
Taking into service
1
Fig. 46: Humidifier bracket
Nasal cannula
Fig. 47: Connection to the nasal cannula
Nasal cannula
Fig. 48: Connection with the O2 tubing
WARNING! Danger of tripping over!
On the back of the Kröber O2 4.0 you will find a winding device for the mains
lead. This should be used when the unit is out of use, to avoid any danger of
tripping over.
78
9 Stand the humidifier into the bracket
1 Plug the FireSafe Nozzle in oxygen
2 Connect the other terminal to the
O2 tubing
(1).
NOTE!
The bracket has the function of
preventing the humidifier from falling
over. It is therefore recommended to
mount the bracket to a wall, a
cupboard, etc.
flow direction into the nasal cannula.
ATTENTION!
Observe flow direction indicated
by the arrow!
ATTENTION!
For the best protection of the
patient, place the FireSafe Nozzle
in the oxygen tubing routing as
close to the patient as possible!
short oxygen tubing (0.33 m).
