PIN-FREE MOISTURE METERS
MANUAL MC-60A
wet spots in the material can still be performed.
To obtain a more accurate measuring result we recommend
measurements in a pile without air spaces between the single parts and
with a minimum thickness of 20 mm for the pile.
BASE
With material thickness < 50 mm the base material is very important.
Avoid a metal base. The best results are achieved if the material to
be measured is hold into the air. Polystyrene material with a minimum
thickness of 20 mm can also be used.
WET SURFACES
In case of material with wet surface a PVC-foil can be used between the
material and measuring springs electrodes.
Approximate reference values Moisture
Content (% H O):
2
Building Material Dry
Breezeblock
(cellular lightweight 0 - 4
concrete)
Bricks, plaster 0 - 2,5
Asbestos cement 0 - 5
Clinker-clay floor
0 - 1,5
tiles, wall tiles
Concrete, cement
0 - 3
wash floor
Gypsum 0 - 1
Marble, sandstone 0 - 1,5
Wood Dry
Parquet flooring 6 - 8
Furniture (indoor) 6 - 9
Door/ window 12 - 15
(outdoor)
(Mould: 18 - 20 %, Rot: >28 %)
When examining wood, make sure that measurements are carried out
in accordance with its fibre direction – otherwise the measured values
will be too low. The measuring direction is correct when the wood fibre
direction is parallel to the indicator.
ENG
Moist Wet
4 - 5 > 5
2,6 - 6.5 > 3,6
5 - 7 > 7
1.5 - 2.0 > 2,0
3 - 4 > 4
1 - 2 > 2
1.5 - 2 > 2
Moist Wet
- 6 -
PIN-FREE MOISTURE METERS
WOOD GROUP TABLE
Name Botanical name (Latin)
Nyatoh Palaquium spp.
Nyatoh batu
Oak, Japanese Quercus crispula
Oak, red Quercus rubra
Oak, stalk grape Quercus-robur-petraea
Oak, stone Quercus ilex
Oak, tasmanian
Oak, white Quercus alba
Obeche Triplochiton slceroxylon
Okan Cylicodisus gabunensis
Okoume Aucoumea klaineana
Olive Olea-europaea-hochstetteri
Olivillo Aextoxicon punctatum
Opepe Nauclea diderichii
Oregon, pine Pseudotsuga menziesii
Ovengkol Guibourtia ehie
Ozigo Dacryodes buettneri
Ozouga Saccoglottis gabonensis
Padouk, african Pterocarpus dalbergiodes
Padouk, african Pterocarpus soyauxii
Padouk, burma- Pterocarpus macrocarpus
Padouk, manila Pterocarpus indicus
Paldao Dracontomelum mangiferum
Paldao- Dracontomelum-dao.-spp.
Palisander, ostind. Dalbergia latifola
Palisander, rio Dalbergia nigra
Palosapis
Panga Panga Millettia stuhlmannii
Partridge Caesalpina granadillo
Pau rosa Swortzia filstuloides, mada-
gascariensis
Pear tree Pirus communis
Pecan
Pencilwood, african Juniperus procera
afrpencilwdom, ,,od
Pencilwood, calif. Libocedrus decurrens
kg/m³ Setting
630
1030
630
650
630
850
660
640
350
820
400
850
580
720
510
690
540
840
680
730
810
480
520
620
830
830
620
760
980
1000
660
710
510
360
- 43 -
600
1000
600
600
600
800
600
600
300
800
300
800
500
700
500
600
500
800
600
700
800
400
500
600
800
800
600
700
900
900
600
700
500
300
