4. Open and close the doors of the appliance and
cabinet simultaneously. Mark the position of the
slider, when you can open and close the door at all
door opening angles properly. Remove the slider
from the guide and fix the slider on the cabinet
door using two short screws. Install the slider cover.
5. Unscrew the guide from the door of the appliance.
6. Repeat steps 2 to 5 to fix the other slider and cover.
1: Screws
7. Provide the guides with sliders and fix the guides
using short screws. Install the guide covers.
1: Slider
8. Check that you can open and close the door
properly. If not, slightly adjust the appliance. Then
fix the bottom bracket on the cabinet using two
long screws.
9. Fix the top bracket on the cabinet using short
screws.
10. Install the rubber seal in the gap between the door
opening side of the appliance and the cabinet.
2: Slider
2: Guide
