BOMANN KS 2197 Bedienungsanleitung Seite 21

Reverse the Door Opening Reverse the Door Opening
Reverse the Door Opening Reverse the Door Opening
If required, the door opening can be moved from the right (supplied condition) to the left side.
WARNING: WARNING:
WARNING: WARNING:
When replacing the door stop, the appliance must be disconnected from the power supply. Always unplug the
appliance first.
NOTE NOTE: : : : NOTE NOTE
• When installing, ask another person to assist.
You need:
screw wrench, Phillips screwdriver as well as a thin-blade screwdriver.
•
• Remove the screw covers at the appliance cover. Unscrew the below screws and remove the cover.
• Dismount the upper door hinge by loosening the screws. Open the appliance door a little and take it care-
fully of the lower door hinge. Place the door on a padded surface to prevent it from scratches.
• Tilt the appliance slightly backwards and block it in this position. Unscrew the feet. Dismount the lower
door hinge by loosening the screws.
• Attach the lower door hinge at the respective opposite appliance side, after you have unscrewed the hinge
pin and used by the other hinge side. Turn in the feet accordingly.
• Replace the appliance upright again. Insert the appliance door on the lower hinge pin and fix the door to
the property position.
• Transfer the upper door hinge at the opposite appliance side, after you have unscrewed the hinge pin and
used by the other hinge side. Put the hinge pin in the hole of the door and tight the screws of the hinge.
• Replace the appliance cover, which you have removed at the beginning. Tight the screws and clip the
screw covers on.
• Check if the door is arranged vertical as well as horizontal, so that a smooth opening and closing of the
door is ensured.
Reverse the freezer flap opening Reverse the freezer flap
Reverse the freezer flap Reverse the freezer flap
opening
opening opening
• Open the freezer flap a little. Press the spring of the lower bracket up slightly
with a small screw-driver and remove the bracket incl. freezer flap.
• Place the blind cap (M) at the opposite side.
• Turn the freezer flap about 180° and press the lower flap bracket into the ap-
propriated fixture of the freezer flap.
• Lift the freezer flap a little and fix it in the upper door bracket, at the same time
you press the lower door bracket in the square hole. Small adjustments to the
top and bottom will easily the mounting of the flap.
21
