USB PLAYBACK
You can connect a USB flash drive (not included) to the USB connector port on the unit
to play MP3/DivX/PICTURE files.
1. Plug the USB flash drive into the USB port on the unit.
2. Press SOURCE button, then press to select "Media". Press to
select "USB" , then press ENTER to confirm. (Note: Select "DVD" to
switch to disc mode.)
For operation of playing files on the USB flash drive, please refer to the section "PLAYING
MP3/DivX/PICTURE FILES"
Note:
• It is recommended USB flash drive when the unit is in OFF mode.
• There are many USB devices in the market. We cannot guarantee to support all
different models. Please try another USB device if your device is not supported.
PLAYING MP3/DivX/PICTURE FILES
This unit can play MP3, DivX and Picture files recorded on CD-R/CD-RW discs or USB
flash drive .
1. Insert a disc.
2. The content of disc will be displayed on screen.
3. Press , , , button to view and select the file that you want to play, then
press ENTER button to confirm the selected file and start playback.
4. Press button to stop playback.
Note: For playing files on USB flash drive, you should plug in the USB flash drive when
the unit is in OFF mode. Turn ON the unit and press SOURCE button to select USB
mode.
Notes:
• Avoid long file names! It is suggested to name the file names using 11 or fewer
characters.
• The total number of files on the disc should not exceed 254.
• The maximum number of directories should not exceed 32.
• The maximum depth level of directories should not exceed 4.
Supporting format:
MP3: 32kbps-320kbps
JPEG: up to 8000X6000 pixels and file size less than 8MB
MPEG: MPEG-1 (ISO/IEC 11172-2), MPEG-2 (ISO/IEC 13818-2), MPEG-4 ASP (DivX)
AVI: up to 720X576
VOB (DVD): 720 x 480i, 720 x 576i, 720 x 480p, 720 x 576p
DivX: 3.11 / 4.0 /5.0
GB - 10
PASSWORD SETUP PAGE
PASSWORD MODE
To turn the password mode ON/OFF.
PASSWORD
This option allows you to set or change the password.
Use , button to select "PASSWORD", press button to highlight "CHANGE", then
press the ENTER button. Press the number buttons to input your 4-digit password until
to "OK" (If the password has not been set yet after you purchase this unit, it is "1369").
SAFETY INSTRUCTION
ATTENTION: To reduce the risk of electric shock, do not
remove the cover or back. There are no user serviceable parts
inside the unit. Refer all servicing to qualified personnel.
The lightning flash with arrowhead symbol within the triangle is a warning sign
alerting the user of "dangerous voltage" inside the unit.
The exclamation point within the triangle is a warning sign alerting the user of
important instructions accompanying the product.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION: Invisible laser radiation when open and interlocks defeated. Avoid exposure
to beam. Class 1 laser product.
GB - 15
DVP-3835 IB MUSE 001 REV0- GB.indd 2
SETUP MENU
Navigating the setup menu
1. Press SETUP to display the setup main menu.
2. Press , to select a menu icon.
3. Press , to select one of the available options under a menu icon.
4. Press to access the submenu and , to select an option.
5. Press ENTER to confirm your selection.
6. Press to return to a previous menu.
7. Press SETUP to exit from the setup menu.
GERNERAL SETUP PAGE
TV DISPLAY
4:3 PANSCAN
• When wide-screen video is played, this mode clips the right and left sides of the image
so that it can be viewed on a conventional screen.
• Some wide-screen DVDs that do not permit Pan Scan mode playback are
automatically played in letterbox mode (black bands top and bottom).
4:3 LETTERBOX
• When wide-screen video is played in this mode on a conventional screen, black bands
appear at the top and bottom of the screen.
16:9 (Wide screen)
• This is the correct mode for playing wide-screen videos on a wide-screen TV.
WIDE SQUEEZE
The wide-screen image will be displayed in full screen in its native aspect ratio and so
does the 4:3 image but with black borders on the left and the right side.
Notes:
• The visible picture size is preset on the DVD disc. Therefore the playback picture of
some DVD discs may not conform to the picture size you select.
• When you play DVD discs recorded in the 4:3 aspect ratio, the playback picture
will always appears in the 4:3 aspect ratio regardless of the TV shape setting in the
function setup menu.
GB - 11
IMPORTANT SAFETY INSTRUCTIONS
NEVER fit make shift stands or legs with woodscrews. Use only approved supports and
fasteners specially designed for the equipment.
NEVER let anyone, especially children, push objects into holes, ventilation slots or any
other opening; this could result in fatal electric shock!
ALWAYS disconnect the AC adaptor when you are not going to use the unit for a long
period of time.
ENSURE that all electrical connections (including the mains plug, extension leads and
interconnections between pieces of equipment) are properly made in accordance with
the instructions given. Switch off the main supply when making or changing connections.
CONSULT your dealer if you are ever in doubt about the installation, operation or safety
of your equipment.
DON'T continue to operate the equipment if it is damaged in any way or if it does not
function normally. Disconnect the AC adaptor and consult your dealer.
DON'T leave equipment switched on when it is unattended unless it is part of it's normal
function to operate in your absence, for example a video cassette recorder with timed
recording facility.
LISTEN to headphones at moderate volume levels; high volume levels can permanently
damage your hearing.
WARNING:
• AC adaptor is used as the disconnect device. It shall remain readily operable and
should not be obstructed during intended use. To be completely disconnected the
apparatus from supply mains, the AC adaptor of the apparatus shall be disconnected
from the mains socket outlet completely.
• Never use an AC adaptor that is damaged, route power lead in a safe manner and
make sure it is not subjected to trapping or pinching. If the power lead is damaged
refer to a qualified service agent.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by
covering it with a cloth, or by placing it on carpeting.
• To avoid magnetized, do not place the unit near speaker or magnet.
• Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht,
etc) where it would be exposed to high temperatures above 40°C.
• It also should not be placed in temperatures less than 5°C or greater than 35°C.
• No naked flame sources such as lighted candles should be placed on the AC adaptor
and main unit.
• Do not use the unit immediately after transportation from a cold place to a warm place,
condensation problem may result.
• The ventilation should not be impeded by covering the ventilation openings with items
such as newspapers, table-cloths, curtains, etc.
• No naked flame sources, such as lighted candles, should be placed on the apparatus.
• The use of apparatus in moderate climates.
• The apparatus should not be exposed to dripping or splashing.
GB - 16
ANGLE MARK
ON: To show angle mark when a disc with multiple camera angles is playing. You can
view different camera angles of a DVD disc by pressing ANGLE button on remote
control.
OFF: To hide angle mark.
NOTE: This function is only available for discs encoded with multiple camera angles.
OSD LANGUAGE
• To select the language of unit's menus.
CLOSED CAPTIONS
Some discs have closed captions.
ON: Show the closed captions.
OFF: Hide the closed captions.
SCREEN SAVER
To set screen saver ON or OFF.
AUTO STANDBY
This function allows you to select the standby setting:
OFF: The unit will not switch to standby mode.
3 HOURS: If no button is pressed within 3 hours, the unit will switch to standby mode
automatically.
4 HOURS: If no button is pressed within 4 hours, the unit will switch to standby mode
automatically.
AUDIO SETUP PAGE
DOWNMIX
LT/RT: left and right soundtrack audio output
STEREO: Stereo audio signal output
DOLBY DIGITAL
DUAL MONO
To select STEREO, L-MONO (left mono), R-MONO (right mono) and MIX- MONO for
Dolby Digital output.
GB - 12
• Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
• Do not place objects filled with liquids, such as vases, on the apparatus.
• The marking plate is located on the bottom of unit.
• Attention should be drawn to the environmental aspects of battery disposal.
• Do not throw batteries in fire!
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
• Excessive sound pressure from earphones and headphones can cause hearing loss.
• Under the influence of electrical fast transient or/and electrostatic phenomenon, the
product may malfunction and require user to power reset.
MAINTENANCE
Cleaning
Be sure to turn the unit off and disconnect the AC adaptor before maintaining the
unit.
• Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
• Using solvents, abrasive or alcohol-based products risks damaging the appliance.
• If an object or liquid enters inside the appliance, unplug it immediately and have it
checked by an authorized engineer.
Note on disc
• Do not use irregular shape CDs (example: heart-shaped, octagonal ones). It may
result in malfunctions.
• Do not place more than one disc in the disc compartment.
• Do not try to open the disc compartment during playing.
• Do not touch the lens. Doing so may cause malfunction.
• If there is a scratch, dirt or fingerprints on the disc, it may cause tracking error. Before
playing, clean the disc with a cleaning cloth. Wipe the disc from the center out. Don't
store discs in places with high temperatures or high humidity, they can become
warped. After playing, store the disc in its case.
Important Note
• Before transporting the unit, remove the disc from the disc compartment.
GB - 17
DYNAMIC
• To control the different sound levels via dynamic compression. It improves the quality
of the sound track at a low volume, and quiets the loudest sounds.
• This function is available only on DVD discs recorded in Dolby Digital.
VIDEO SETUP PAGE
BRIGHTNESS: To adjust the video brightness level on a scale of -16 to +16.
CONTRAST: To adjust the video contrast level on a scale of -16 to +16.
HUE: To adjust the color hue level on a scale of -9 to +9.
SATURATION: To adjust the color saturation level on a scale of -9 to +9.
DivX VOD
• Some DivX Video-On-Demand files required registration code, please get the code of
your DVD player.
• Registration code is for DivX Video-On-Demand only, do not apply this code for
another applications or websites.
PERFERENCE PAGE
Note: The Preferences Setup menu is only available at stop mode.
TV TYPE
• To select your TV system among PAL, AUTO or NTSC.
GB - 13
MOUNTING BAG INSTALLATION
SAFETY WARNING!
On no account should this unit be used by the driver of a moving motor vehicle, or left
unsecured in the vehicle whilst driving. If this unit is being used by a passenger in your
vehicle, be sure that it is secured or held safely, and does not obstruct any safety device
(i.e. airbag, seat belt etc.) that is fitted.
1
2
3 4
1. Insert the unit into bag as shown.
2. Take straps and hook up the neck headrest of the seat as shown.
3. Adjust the straps tightly so that the unit is secured.
4. Connect the 12V car plug as shown.
CAUTION: Using other car plugs could damage the unit.
GB - 18
AUDIO
• To select the dialog language.
• If the selected language is not available on the disc, the disc's language will be used
instead.
• To change the dialog language during playback, press AUDIO on the remote control.
SUBTITLE
• To select the language of the DVD subtitles. Select "OFF" to turn off the subtitles.
• If the selected language is not available on the disc, the disc's language will be used
instead.
• To change the subtitle language during playback, press SUBTITLE on the remote
control.
DISC MENU (menu language)
• To select the language of the DVD menus.
• If the selected language is not available on the disc, the disc's language will be used
instead.
PARENTAL
Some DVD discs are equipped with a password function and are rated according to
their content. The contents allowed by parental lock level and the way a DVD disc is
controlled may vary from disc to disc. For example, if the disc allows, you could lock-
out violent scenes unsuitable for children or you could lock out playback of the disc
altogether.
You cannot play DVD discs rated higher than the level you selected unless you cancel
the parental lock function.
The parental lock levels are equivalent to the following ratings.
Level 1 : Kid Safe
Level 2 : G
Level 3 : PG
Level 4 : PG-13
Level 5 : PG-R
Level 6 : R
Level 7 : NC17
Level 8 : Adult
MEPG4 SUBTITLE
If your DivX video file includes subtitle file, use this to select your preferred subtitle
language.
DEFAULT
Pressing ENTER with this function selected resets all settings to their initial factory
state, except for parental level and password.
GB - 14
TROUBLE SHOOTING
No power.
• Ensure the AC adaptor is connected.
• Make sure that the unit is turned on.
The remote control does not function.
• Make sure the infrared remote sensor is not blocked.
• Point the remote directly at the infrared remote sensor on the unit.
• Replace the battery in the remote with a new one.
Very little or no sound is coming from a DVD.
• Make sure that the unit is turned ON.
• Make sure the unit is not paused. Press .
• Make sure the unit is not in fast-forward or fast-reverse mode. Press .
• Make sure that the connections are correct.
• Make sure the MUTE function is not on.
The player does not start playback
• Insert the disc with the printed side facing up.
• Check that the disc can actually be played by this device.
• Check that the disc's regional code matches the player's regional code. This player's
regional code is 2.
• Clean the disc.
The picture is not clear.
• The DVD is dirty. Gently clean the disc.
• The disc is scratched.
• Please adjust the LCD's brightness and contrast in SETUP MENU.
Forget Password
If you forget your own password, enter "1369" to reset.
Specifications and appearance are subject to change without notice.
NEW ONE S.A.S
10, Rue de la Mission, 25480 Ecole Valentin, France
GB - 19
M-1070DP/IB/V0
2016/8/19 15:58:20
