If replacing the battery, remove the old battery from the battery compartment.
Leaky or damaged batteries might cause cauterisation when in contact with the skin; therefore, use suitable
protective gloves.
Only replace by the same type or similar types recommended by the manufacturer.
Remove empty battery in accordance with the instructions of the manufacturer.
Insert the battery and make sure that the poles are correct.
Replace the battery cover and close it.
If the device will not be used for a longer period of time, remove the battery in order to avoid battery leakage.
In order to have a long battery life, you should only use alcaline batteries.
Batteries are hazardous waste and should not be disposed of with regular domestic waste!
Please take old and used batteries to a collection center near you.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Number of DMX control channels:
DMX-512 connection:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
LED type:
Number of LEDs:
Beam angle:
Dimensions (LxWxH):
Weight:
Accessories:
EUROLITE IR remote 2
EUROLITE TH-50 Theatre hook, silver
EUROLITE TH-50S Theatre hook, black
Safety bond A 3x600mm up to 5kg, silver
Safety bond A 3x600mm up to 5kg, black
Please note: Every information is subject to change without prior notice. 27.09.2012 ©
Danger of explosion when battery is replaced improperly.
BATTERY DISPOSAL NOTICE
Please dispose of old and used batteries properly.
:
a
(steady state):
C
Caution!
230 V AC, 50 Hz ~
70 W/120 VA
2
3-pin XLR
via built-in microphone
45° C
up to 65° C
0.50 m
0.10 m
F 2 A, 250 V
Cluster, 60 W UV
1
25°
125 x 335 x 350
4 kg
No.
51930201
58000650
58000651
58010310
58010342
23/23 00069528.DOC, Version 1.1
