The different functions of the individual notes are as follows:
Note Velocity
22-69 Program Master
70-93 Channel dimmer
94
95
96
97
98
99
100
101
102
Receive a Sys-Ex dump
Press and hold the Record-button.
Press the Flash-button 3 in Preset A three times.
Release the Record-button.
When the display will show In, the controller is ready for receiving the dump.
When receiving the dump, all other functions are switched off. As soon as the transmission is complete or
cancelled due to errors, the controller returns to normal operation mode.
Send a Sys-Ex dump
Press and hold the Record-button.
Press the Flash-button 4 in Preset A three times.
Release the Record-button.
When the display will show Out, the controller is ready for sending the dump.
When sending the dump, all other functions are switched off. As soon as the transmission is complete or
cancelled due to errors, the controller returns to normal operation mode.

7. PROBLEM CHART

PROBLEM
No power.
Display shows LOP.
Cannot memorize Scene.
Cannot edit programs.
Programmed scene/chaser
disappeared.
Cannot display
scene/chaser.
No signal output.
Function
Turn on/off program 1-48
Turn on/off channel 1-24
Full On
Dark
Hold
Turn Audio chase on/off
Chaser/Scenes
Double Preset Mode
Single Preset Mode
Change step
Blackout
CAUSE
The power unit is not connected.
Operating volatage is too low.
Record-button forgotten.
Program mode locked.
Selected wrong page.
Wrong fader-setting.
Blackout-mode activated.
Check the connection cable of the
power unit and any extension-cables.
Check the connection cable of the
power unit and any extension-cables.
Press the Record-button after setting
the channels.
Unlock program mode.
Select correct page via the Page-
button.
Adjust Master-fader to maximum, the
Fade-fader and Speed-fader to the
desired setting.
Switch off blackout by pressing the
Blackout-button.
25/26
REMEDY
