Vorbereitung ................10 COMfortel WS-R2/WS-R4 an der Wand montieren................. 10 COMfortel WS-R2/WS-R4 reinigen ......... 11 Inbetriebnahme ..............12 COMfortel WS-R2/WS-R4 für die Einrichtung vorbereiten ..12 COMfortel WS-R2/WS-R4 einrichten........13 COM-Port einstellen............14 Als Mehrzellensystem einrichten........14 COMfortel WS-R2/WS-R4 anschließen ........16 Lizenzen/Licenses ..............
Seite 4
Additional Instructions ............21 The Latest Information ............21 Copyright and Trademarks..........21 Preparation................22 Mounting the COMfortel WS-R2/R4 on the Wall ..... 22 Cleaning the COMfortel WS-R2/R4 ......... 23 Commissioning..............24 Preparing the COMfortel WS-R2/R4 for Configuration .... 24 Configuring the COMfortel WS-R2/R4........
Wichtige Informationen Dieser Abschnitt enthält die für einen sicheren Betrieb notwendi- gen Informationen. Bevor Sie den COMfortel WS-R2/WS-R4 in Betrieb nehmen, lesen Sie unbedingt die hier aufgeführten Sicherheitshinweise und machen Sie sich mit der bestimmungs- gemäßen Verwendung des Geräts sowie den technischen Daten vertraut.
Lassen Sie von einer Elektrofachkraft alle Kabel innerhalb des Gebäudes verlegen. Schützen Sie die Geräte durch Installation eines Überspan- nungsschutzes. Bestimmungsgemäße Verwendung Wichtig: Produkte von Auerswald sind nicht dafür ausgelegt und sollten daher nicht für lebenserhaltende Systeme und/oder COMfortel WS-R2/WS-R4 - Inbetriebnahme V04 11/2015...
Seite 7
Sie Ihren Fachhändler. Lesen Sie die zum Gerät gehörenden Anleitungen und bewahren Sie diese zum späteren Gebrauch auf. Bei den Geräten COMfortel WS-R2/WS-R4 handelt es sich um IP-DECT Repeater. Der COMfortel WS-R2/WS-R4 vergrößert die Reichweite einer COMfortel WS-Base, oder eines WS-400 IP (Multi).
Gewicht Ca. 160 g Sicherheit Umwelthinweise Entsorgung Sollte das Auerswald-Gerät einmal ausgedient haben, achten Sie auf die fachgerechte Entsorgung (nicht in den normalen Hausmüll). Entsorgen Sie das Verpackungsmaterial im Interesse des Umweltschutzes ordnungsgemäß. Erkundigen Sie sich bei der Stadt- oder Gemeindever- waltung nach Möglichkeiten einer umwelt- und sachge-...
Mitteilung des Inhalts, auch auszugsweise, ist nur mit unserer ausdrücklichen Genehmigung gestattet. Zuwiderhand- lung verpflichtet zu Schadenersatz. Alle Rechte vorbehalten. Auerswald GmbH & Co. KG, 38162 Cremlingen, 2015 Alle genannten Marken sind Eigentum der jeweiligen Hersteller. COMfortel WS-R2/WS-R4 - Inbetriebnahme V04 11/2015...
Vorbereitung Dieser Abschnitt beschreibt die vor der Inbetriebnahme des Geräts notwendigen Vorbereitungen. COMfortel WS-R2/WS-R4 an der Wand montieren Der COMfortel WS-R2/WS-R4 ist für die Wandmontage in geschlossenen, trockenen Räumen vorgesehen. Voraussetzungen – Werkzeug und Material: Bohrmaschine und Schraubendreher Die im Lieferumfang enthaltenen Schrauben und Dübel –...
Gerät beschädigen oder zerstören. Reinigen Sie das Gehäuse des Geräts nur mit einem leicht feuchten Tuch oder einem Antistatiktuch. Achtung: Die Oberfläche kann durch Reinigungsmittel beschädigt werden. Verwenden Sie keine scharfen oder lösemittelhaltigen Reini- gungsmittel. COMfortel WS-R2/WS-R4 - Inbetriebnahme V04 11/2015...
Inbetriebnahme Dieser Abschnitt beschreibt Inbetriebnahme COMfortel WS-R2/WS-R4. Dazu gehören die Vorbereitung des Geräts, die Erstellung einer ersten Konfiguration und das Anschließen. Übersicht Inbetriebnahme COMfortel WS-R2/WS-R4 für die Einrichtung vorbereiten (Seite COMfortel WS-R2/WS-R4 einrichten COM-Port einstellen (Seite Als Multizellensystem einrichten (Seite COMfortel WS-R2/WS-R4 anschließen...
Die LED auf der Vorderseite des Gehäuses blinkt rot. Der Repeater wird gestartet und kann mit dem Service- Tool eingerichtet werden. COMfortel WS-R2/WS-R4 einrichten Hinweis: Detaillierte Informationen zur Einrichtung des COMfortel WS-R2/WS-R4 finden Sie in der Hilfe des Service Tools. COMfortel WS-R2/WS-R4 - Inbetriebnahme V04 11/2015...
Wählen Sie in der Liste COM-Port Auswahl den COM-Port, der im PC für den USB/RS-232-Adapter eingestellt ist (siehe Gerätemanager des PCs). Wählen Sie unter Baudrate die Option COMfortel WS-R2/ R4 (9600 baud). Klicken Sie auf COM-Port. Der Repeater verbindet sich mit dem PC. In der Status- zeile wird Repeater verbunden angezeigt.
Seite 15
> Wireless Server. Anzahl Kanäle für Transfer (Busy Bit): Geben Sie die Anzahl der Sprachkanäle ein, die der Repeater verwaltet (COMfortel WS-R2 max. 2 Kanäle, COMfortel WS-R4 max. 4 Kanäle). Basis für Synchronisierung: Geben Sie die Nummer der Mehrzellen-Basis ein, mit der sich der Repeater syn- chronisiert.
Stecken Sie den Stecker des Steckernetzteils in die RJ-10- Buchse auf der Unterseite des Geräts. Stecken Sie das Steckernetzteil in eine Netzsteckdose. Der Repeater synchronisiert sich mit der Mehrzellen-Ba- sis. Die LED auf der Vorderseite des Gehäuses leuchtet rot. COMfortel WS-R2/WS-R4 - Inbetriebnahme V04 11/2015...
If the wall wart is damaged, disconnect the fuse for the power supply before pulling out the wall wart plug. Ensure you comply with the relevant regulations when han- dling supply voltage and devices attached to the power sup- ply. COMfortel WS-R2/WS-R4 - Setup Guide V04 11/2015...
Our products can only be used for these purposes with prior written permission from Auerswald in each individual case. COMfortel WS-R2/WS-R4 - Setup Guide V04 11/2015...
Read the instructions for the device and keep them for future reference. The COMfortel WS-R2/R4 are IP-DECT repeaters. The COMfortel WS-R2/R4 increases the range of a COMfortel WS-Base, or a COMfortel WS-400 IP (Multi). Up to 3 repeaters can be configured per COMfortel WS-Base (cir- cularly around the base or in series) and up to 3 repeaters per COMfortel WS-400 IP (Multi).
Approx. 160 g Safety Environmental Notice Disposal If you want to dispose of your Auerswald device, please ensure the professional disposal. Do not put it in the normal household waste. Dispose of the packaging material properly and in inter- est of the environmental protection.
Preparation This section describes the preparations required before commis- sioning the device. Mounting the COMfortel WS-R2/R4 on the Wall The COMfortel WS-R2/R4 is designed to be mounted on the wall of a closed, dry room. Requirements – Tools and materials:...
Only clean the casing of the device with a slightly damp cloth or an anti-static cloth. Caution: Cleaning agents may damage the surface. Do not use caustic or solvent-containing cleaning agents. COMfortel WS-R2/WS-R4 - Setup Guide V04 11/2015...
Only use the wall wart supplied with the equipment. Important: You cannot configure the COMfortel WS-R2/R4 unless you perform the steps in the correct order. The following steps must be performed in exactly this order: Insert the splitter plug into the RJ-10 socket on the bottom side of the repeater.
The LED on the front side of the casing flashes red.You can use the ServiceTool to configure the repeater. Configuring the COMfortel WS-R2/R4 Note: You will find more information about the configuration of the COMfortel WS-R2/R4 in the help of the ServiceTool. COMfortel WS-R2/WS-R4 - Setup Guide V04 11/2015...
In the Comport setting list, select the COM port which was configured on the PC for the USB/RS-232 adapter (see the PC's Device Manager). Under Baud rate, select COMfortel WS-R2/R4 (9600 baud). Click Set Comport. The repeater connects to the PC. You now see Re- peater connected in the status line.
Seite 27
Number of channels to transfer (Busy Bit): Enter the number of voice channels you want the repeater to man- age (for COMfortel WS-R2, maximum 2 channels, for COMfortel WS-R4, maximum 4 channels). Base station to synchronize on: Enter the number of the base station you want the repeater to synchronise with.
Insert the wall wart plug into the RJ-10 socket on the bottom side of the device. Insert the wall wart plug into a power socket. The repeater synchronises itself with the base station. The LED at the front is red. COMfortel WS-R2/WS-R4 - Setup Guide V04 11/2015...
Products. Such warranties, however, are the sole and exclusive liability of Auerswald, and Auerswald is not authorized to make any warranties to you for or on behalf of the manufacturer of the Products. 5. You agree that (1) the manufacturer of the Product is a third-party beneficiary of these terms, and (2) the license, restrictions and confidentiality provisions set forth herein are made for the express benefit of the manufacturer of the Product and are enforceable by Auerswald’s licensor as well as Auerswald.
