Smartwares 5745 Montageanleitung Seite 4

The alarm silence (STILL button) is extremely useful in a
kitchen area or other areas prone to nuisance. The hush
feature is to be used only when a known alarm condition, such
as smoke from cooking activates the alarm. The smoke alarm
device is desensitized by push the alarm silence (hush mode)
on the smoke alarm device cover, if the smoke is not too
dense, the alarm will silence to indicate that the alarm is in a
temporarily desensitized condition. The smoke alarm device
will automatically reset after approximately 5 minutes, if after
this period, particles of combustion are still present, the alarm
will sound again. The alarm silencer (hush mode) can be
repeatedly until the air has been cleared of the condition
causing the alarm.
NOTE: Dense smoke will override the alarm silencer and
sound a continuous alarm, the smoke alarm goes back to
normal work status from hush mode
CAUTION : Before using the alarm silence (hush), identify the
source of the smoke and be certain a safe condition exists.
PREVENTIVE MAINTENANCE
TESTING
The smoke alarm device is provided with a TEST button. Push it
in until the alarm sounds. The signal stops when the button is
released. Test the alarm at least once a week.
CLEANING
For the best performance, the smoke alarm device must be
dusted once a month and vacuumed every 6 months. Remove
the detector from the ceiling plate and carefully vacuum the
detector. Do not touch the inside with the nozzle of the vacuum
cleaner. Then test the alarm.
CAUTION : The smoke detector loses its effectiveness
if it is covered.
WARNING : The smoke alarm device should not be painted /
taped. Do not test the smoke alarm device with
candles, flames, cigarettes, etc.
IN CASE OF FIRE ALARM
A smoke alarm device is part of your fire protection together
with fire extinguishers, escape ladders, ropes as well as your
choice of building materials during renovations. Also make sure
that there is an escape route; discuss this with your children,
make sure any room can be evacuated without opening the
door, for example through a window. If the smoke alarm
device is not working properly, consult the instructions of the
supplier. Keep the manual within reach. The local fire
department can provide more information about fire prevention.
Keep the smoke detector away from children.
TROUBLESHOOTING
The alarm does not sound when pressing the test button.
* Carefully vacuum the smoke alarm device (see Cleaning), test
afterwards. Still no reaction; replace smoke detector
The alarm "chirp" with red LED flashes once every 40 sec.
* The battery is under low battery status, please replace the
smoke alarm device; battery is not replaceable.
Smoke alarm device sounds unwanted alarms intermittently
or when resident are cooking or taking showers.
* Press STILLE button to pause alarm.
* Clean smoke alarm device (maintenance section)
* Move smoke alarm device to other place and press test button
If these actions do not solve the problem, do not try to repair it
yourself. If the problems occur within the warranty period and
are under warranty conditions, return the smoke alarm device
plus valid proof of purchase with a clear description of the
complaints to:
Smartwares safety & lighting
Can never be held liable for loss and / or damages of any kind,
including incidental and or consequential damages arising out
of the fact that the signal from the smoke alarm device is not
triggered by smoke or fire.
WARNING
If there is any doubt about the cause of the alarm, assume that
there really is a fire and carry out your emergency plan. Please
do not assume that it is a false alarm. Dust can cause
excessive sensitivity. Vacuum as indicated above. Do not paint
the smoke alarm device.
FALSE ALARM
Unusual atmospheric conditions may be the cause that the
very sensitive smoke detector gives a false alarm. If there is no
fire, ventilate the room and / or blow clean air in the smoke
alarm device, for example, by waving a newspaper under the
smoke alarm device until the alarm stops. Once it is clean,
there is an automatic reset.
RECOMMENDATION
We recommend that you do not use smoke alarm devices that
are older than 10 years in order to limit the risk of defects. The
smoke alarm device is not a substitute for insurance for
furniture, home, life, or other form of insurance.
SPECIFICATIONS
Power : 3x 3V DC CR123A Lithium
(not replaceable battery)
Operating temperature : 4 ~ 38°C
Operating humidity : 25 ~ 85%
Smoke sensor : Optical
Alarm volume : > 85db(a) at 3 meters.
Mounting type : Ceiling
Use motor home/caravan : No
Individual Alarm Indicator : Yes
Pause time : Approx. 5 minutes
DECLARATION OF PERFORMANCE
Step 1 : Go to service.smartwares.eu
Step 2 : Go to 1. Find manuals and support
for your product
Step 3 : Fill in article number: RM220
Step 4 : Download DoP
INTENDED USE: FIRE SAFETY
ESSENTIAL CHARACTERISTICS: PASSED
- Nominal activation conditions/ Sensitivity, Response delay
(response time) and Performance under fire condition
- Operational reliability
- Tolerance to supply voltage
- Durability of operational reliability and response delay,
temperature resistance
- Durability of operational reliability, vibration resistance
- Durability of operational reliability, humidity resistance
- Durability of operational reliability, corrosion resistance
- Durability of operational reliability, electrical stability
PRODUCT GUARANTEE
This product has factory warranty according to EU regulations.
Guarantee lasts for the number of years shown on the
packaging, starting from the date of purchase.
Keep the receipt - proof of purchase is required in order to rely
on guarantee. In the case of problems, please contact with the
store where you purchased the product. For information visit
our website: www.smartwaressafetylighting.eu.
15
Passcode / LE: RM220-001CPR
1134
Fire Safety EN14604:2005/AC:2008
DISPOSAL PRODCUT
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment) (Applicable in the European Union
and other European countries with separate collection
systems)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life. To
prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.Household users
should contact either the retailer where they purchased this
product, or their local government office, for details of where
and how they can take this item for environmentally safe
recycling. Business users should contact their supplier and
check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for
disposal.
DISPOSAL BATTERIES
Always throw empty batteries to the battery recycling
bin. If the battery is built-in inside the product, open the
product and remove the battery.
MAINTENANCE
The devices are maintenance-free, so never open
them. The guarantee becomes void when you open the
appliance.Only clean the outside of the devices with a soft, dry
cloth or a brush. Prior to cleaning, remove the devices from all
voltage sources. Do not use any carboxylic cleaning agents or
petrol, alcohol or similar. These attack the surfaces of the
devices. Besides, the vapors are hazardous to your health and
explosive. Do not use any sharp edged tools, screw drivers,
metal brushes or similar for cleaning. Warning: Protect the
battery against fire, too much heat and sunshine
GENERAL SAFETY
* Wipe clean with a dry cloth or brush.
* Do not use abrasive solvents.
* Avoid moisture on all electrical components.
* Keep all parts away from young children's reach
* Do not store this item on wet, very cold or warm places, this
can damage the electronic circuit boards.
* Avoid dropping or shocks, this can damage the
electronic boards
* Repairs or opening of this item may only be performed by
an authorised workshop.
* Keep batteries out of the reach of children. Batteries not
swallow. When a cell or battery is swallowed, call a
physician immediately.
Indoor
use
only CUSTOMER SERVICE
safet y & lighting B.V.
0800 333 00 888
www.smartwares.eu
smartwares-service-de@teknihall.com
G215025
VdS3131
