Buttons/Led; Display; Installation; Battery Installation - Topcom Allure 200 Bedienungsanleitung

Topcom Allure 200

1 BUTTONS/LED

1 'Handsfree' indicator
2 'New Calls' indicator
3 Direct Memory buttons (M1-M8)
4 Music on Hold button
5 Volume Down / VIP button
6 Volume Up / Delete button
7 Phone Book button
8 Up button
9 Down button

2 DISPLAY

Display information Description
You received new messages in the telephone network mailbox
XX NEW You have received 'XX' new messages in your call list
REP You have received the call more than once
VIP You have selected the number as VIP
The battery is almost empty and needs to be replaced
The handsfree function is activated
The alarm is enabled

3 INSTALLATION

3.1 Battery installation

• Put batteries in the battery compartment to activate the display :
- Open the battery compartment at the bottom of the unit using a screwdriver.
- Insert 3 AAA Alcaline batteries (1,5V).
- Close the battery compartment.
Connect one end of the line cord to the telephone line wall socket and the other end to the bottom of the phone.
Note:When the battery indicator
removed, you have 5 minutes to replace them. After that time, the memory will be lost.
Never change batteries when the telephone line is connected !

3.2 Initialization

a. Display language
After installing the batteries, the default display language is shown.
• Use the Up or Down
• Press the Handsfree button
b. Memory capacity
The maximum capacity of the Allure 200 is 110 entries including names and numbers.
This number can be dedicated to the Phonebook and/or the Caller ID list. In this setting you have to select the capacity
of the Phonebook.
• Use the Up or Down
• Press the Handsfree button
• The Caller ID list memory size will be displayed briefly and the unit will go to standby mode.
To have access to the memory setting, you have to remove the batteries for more than 10 minutes.
All stored information will be erased after initialisation.
4
/VIP
/
is shown, the batteries must be replaced. When the batteries are
button to select the desired display language.
to go to the next setting 'Memory capacity'
button to select the phonebook memory 'MAX DATABANK = XXX (default 032)'
to confirm the phonebook memory.
10 Dial / Alarm button
11 Flash
12 Mute button
13 Redial / Pause button
14 Handsfree button
15 Alphanumerical keyboard
16 Ring volume switch
17 Flash time switch
18 Telephone line input
/
Topcom Allure 200
