To set / recall the radio presets
1. Press the ON/OFF button (6) to turn the unit ON.
2. Use the Tune + or Tune - button to select the desired radio station.
3. Press and hold the memory / memory + button; "P01" will blink in the display.
4. Use the Tune+ or Tune- button to select the desired preset station (P01-P10)
5. Press the memory / memory + button again to set the preset.
6. Repeat steps 2 through 5 to set more presets.
7. The unit can preset 10 stations totally for FM.
8. When "P01-P10" is blinking, press the Tune+ or Tune- button to select the
preset number.
9. When recalling preset stations, press memory / memory + button to select
the preset number.
RESETTING
If the system does not respond or exhibits erratic or intermittent operation, you
may have experienced an electrostatic discharge (ESD) or a power surge that
triggered the internal microcontroller to shut down automatically. If this occurs,
simply disconnect the ac power cord and remove the system backup battery,
wait for at least 3 minutes and then setup the unit again as if it is a brand new
unit.
Power Supply
Power consumption
Standby power consumption
Battery backup
Radio Frequency Coverage
Audio output power
Net Weight
Dimensions
Due to continual revision and improvement on our products design,
specifications are subject to change without further notice.
This product was imported by the Company : DEMSA S.A.S.
For any questions concerning the conformity of the product, thank you to send
your request to :
TECHNICAL SPECIFICATIONS
• AC 230V - 50 Hz
• 5W
• <1W
• 3V (CR2032 Flat Lithium battery x 1) not
included
• FM: 87.5MHz - 108 MHz
• 180MW RMS
• 0.36kgs
• 138 x 65 x 80 mm mm
IMPORTANT:
EXCLUSIVE IMPORTER
DEMSA S.A.S.
28, Boulevard Zéphirin Camélinat
92230 GENNEVILLIERS
FRANCE
18
