Press the PREVIOUS key to adjust the centre frequency of the filter.
OUT 5&6
Eq1S Fq
Pressing PREVIOUS again, adjust now the amount of EQ boost. Set it to +5dB.
OUT 5&6
Eq1S +-
The next screen that appears refers to the bandwidth (Wd) of the EQ filter. Leave the value at the
default setting, i.e. 0,3 octaves.
OUT 5&6
Eq1S Wd
The parameters used to set up the outputs 5 and 6 give place to following frequency response curve,
corresponding to the high frequency way.
ECLER S.A.
+10
+5
+0
-5
d
-10
B
-15
r
-20
A
-25
-30
-35
-40
10 20
Once all three outputs have been configured, the frequency response curve of the DP300 has following
appearance:
ECLER S.A.
+10
+5
+0
-5
d
-10
B
-15
r
-20
A
-25
-30
-35
-40
10 20
After this procedure, a stereo 3 way system with filters for low, mid and high frequencies has been set
up.
High
14.9kHz
High
+5dB
High
0.3Oct
50 100 200
50 100 200
500 1k 2k
Hz
500 1k 2k
Hz
01/31/05 15:40:14
5k 10k 20k
01/31/05 15:41:52
5k 10k 20k
