PA408
Linear increase: Display scaling defines interaction of input signal and displayed
Displayed
value 2
Displayed
value 1
Measured Measured
value 1 value 2
Linear decrease: There are two options to enter the value coordinates: Either by
Displayed
value 1
Displayed
value 2
Measured Measured
value 1 value 2
7 6 5 4 3
No. Description
1 Display
2 Sticker
3
LED 2
4
Key
5
Key
6
Key
7
LED 1
24

2 Description

2.1 System description

The process display is intended as indicator for measured values in
industrial applications.
- Inputs: Voltage ±10 V, ±200 V / Current ±20 mA / thermocouples
J,K,T,N, Pt100, Pt1000 / resistance measurement / potentiometer
- Display range can be linearised
- Two limits output
- Min, Max functions
- Sensor supply
- LED display, 4-digits, 14 mm or 20 mm high
- DIN housing 96 x 48 mm

2.2 Display range

value. Linear behavior requires defining two measured values - (inP)
respectively displayed values (dSP). Both limits should be at the
end of the display area to ensure maximum precision.
keypad (in SCAL mode) or using the teach-in feature (teach mode).
Assigning the displayed values requires manual entry (with device
still in teach mode).
Display
1
2
Function operating mode
4-digits LED display
Unit sticker position
Status display output 2
Programming access
MIN/MAX display
Status display output 1
www.baumer.com
Function programming mode
Limit 2 programming
Selection of programming line
Digit/function selection
Incrementing the selected digit
Limit 1 programming
