Max. offset
Cable resistance per wire (max.)
Sensor current
Effect of sensor cable resistance (3- / 4-wire)

Sensor error detection

TC INPUT
Type Min. temperature
B 400 °C
E -100 °C
J -100 °C
K -180 °C
L -100 °C
N -180 °C
R -50 °C
S -50 °C
T -200 °C
U -200 °C
W3 0 °C
W5 0 °C
LR -200 °C
Max. offset
Cold junction compensation
Sensor error detection
Sensor error current

VOLTAGE INPUT

Measurement range
Min. span
Max. offset
Input resistance
OUTPUT
CURRENT OUTPUT
Signal range
Min. signal range
Updating time
Output signal at EEprom error
Load resistance
Load stability
SENSOR ERROR DETECTION
Programmable
NAMUR NE43 Upscale
NAMUR NE43 Downscale
Of span =
© Danfoss | DCS (im) | 2017.07
Max. temperature
1820 °C
1000 °C
1200 °C
1372 °C
900 °C
1300 °C
1760 °C
1760 °C
400 °C
600 °C
2300 °C
2300 °C
800 °C
When detecting
Else
50% of selec. max. value
5 Ω
nom. 0.2 mA
< 0.002 Ω / Ω
Yes
Min. span Standard
200 °C IEC584
50 °C IEC584
50 °C IEC584
50 °C IEC584
50 °C DIN 43710
100 °C IEC584
200 °C IEC584
200 °C IEC584
50 °C IEC584
75 °C DIN 43710
200 °C ASTM E988-90
200 °C ASTM E988-90
50 °C GOST 3044-84
50% of selec. max. value
≤ ± 1.0 °C
Yes
nom. 33 mA
0 mA
-12 – 800 mV
5 mV
50% of selec. max. value
10 mΩ
4 – 20 mA
16 mA
440 ms
≤ 3.5 mA
≤ (V - 7.2) / 0.023 [Ω]
supply
≤ ±0.01% of span / 100 Ω
3.5 – 23 mA
23 mA
3.5 mA
Of the presently selected range
