DMX PERSONALITY
3.8
Enter DMX MODE to select DMX Channel alignment.
MENU
PERSONALITY
3.9 TEST
Using TEST mode allows to check fixture for function. Beam as
well as Aura or full fixture can be tested.
MENU
TEST
LINEAR CTO
3.10
In LINEAR CTO menu several preprogrammed white´s can be
choosen.
MENU
LINEAR CTO
3.11 BALANCE PARAMETERS
In CALIB Menu the RGB output of the Beam LED´s can be calibrat-
ed seperatly.
For using the calibrated colors, it has to be activated in SET -
WHITE BALANCE.
MENU
SET
CALIB.
STANDARD
BASIC
EXTENDET
BEAM
AURA
ALL
2700 K
3200 K
4200 K
5600 K
6500 K
7200 K
8000 K
10000 K
WHT BALAN
ON/OFF
BEAM 1
R. (0-255)
G. (0-255)
B. (0-255)
BEAM 2 R. (0-255)
G. (0-255)
B. (0-255)
25
