Important: If you exit playback mode while the motion sensor is active, the sensor is triggered by a
comparison between the played-back sequence and the live picture. You should therefore disable the motion
sensor before starting playback mode.

System options

Press the [MENU] key to open the program menu. Press [←] or [→] to move to the field to the left or right.
Keep one of these keys pressed for more than 1 second for fast forward/backward.
Press [+] or [–] to increase/decrease values. Keep one of these keys pressed for more than 1 second to
change values fast in the respective direction.
Press [NEXT PAGE] to reach the next menu page or exit the menu.

Date and time settings

Date Format: Sets the data format for the live display (Year: YY, Month: MM; Day: DD).
Location: Positions the date and time on the screen. Change the position by pressing [+] and [–] (see Fig. 2).
LEFT TOP
2003.11.06
LEFT BOTTOM
2003.11.06
10：20：36
MONITOR OUT DATE\ TIME: If this is set to "ON", the date and time are shown on the screen.
VCR OUT DATE\ TIME: If this is set to "OFF", the time and date are not transmitted to the recorder during
recording.
SEQUENCE: Defines 8 positions for the sequential display of connected cameras.
Codes as follows:
... DATE/TIMES SETUP ...

DATE FORMAT:

DATE: 2003.08.27
TIME: 12:35:50
LOCATION:BOTTOM
MONITOR OUT DATE\TIME: ON
VCR OUT DATE\TIME: ON
-- SEQUENTIAL SETTING —-
SEQUENCE:
Q 1 2 3 4 . . .
DWELL TIME:
3 3 3 3 3 0 0 0
TOP 2003.11.06 10：20：36
BOTTOM 2003.11.06 10：20：36
Fig. 2: Positioning of date and time
Q: Quad display of all connected cameras; 1: Camera 1;
2: Camera 2; 3: Camera 3; 4: Camera 4;
YY.MM.DD
Fig. 1:
RIGHT TOP
2003.11.06
10：20：36
:Skip
25
RIGHT BOTTOM
2003.11.06
10 : 20 :36
