Table of Contents
1
Information concerning these instructions . 27
2
Hazard information . . . . . . . . . . . . . . . . . . . . 27
3
Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4
5
6
Installing the shutter contact. . . . . . . . . . . . . . 31
6.1
6.2
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7
Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.1
7.2
Teaching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8
Device LED feedback. . . . . . . . . . . . . . . . . . . . 41
9
10
11
12
26
1
Information concerning these
instructions
Read these instructions carefully before beginning
operation with your HomeMatic components.
Keep the instructions handy for later consultation!
Please hand-over the operating manual as well
when you hand-over the device to other persons
for use.
Symbols used:
Note! This indicates a hazard.
Note. This section contains additional impor-
tant information!
2
Hazard information
Do not open the device. It does not contain any
parts to be maintained by the user.
This device is to be operated indoors only and keep
away from the influences of humidity, dust and
sunshine or other radiating heat sources.
