LANCOM ES-2126+ und LANCOM ES-2126P
Kapitel 5: Operation of CLI Management (englisch)
246
Argument:
<port_range>: which port(s) you want to set PVID(s). Syntax 1,5-7,
available from 1 to 26
<pvid>: which PVID you want to set, available from 1 to 4094
<default_priority>: which priority you want to set, available from 0 to 7
Possible value:
<port_range>: 1 to 26
<pvid>: 1 to 4094
<default_priority>: 0 to 7
Example:
PSES-2126C(VLAN)# set pvid 3,5,6-8 5 6
set tag- group
Syntax:
set tag-group <vid> <name> <member_range> <untag_range>
Description:
To add or edit the tag-based VLAN group.
Argument:
<vid>: VLAN id, from 1 to 4094
<name>: tag-VLAN group name
<member_range>: member port; syntax: 1,5-7, available from 1 to
26
<untag_range>: untagged out port; syntax: 1,5-7, available from 0 to
26
set untag_range to 0 as none of the ports are force untagged
Possible value:
<vid>: 1 to 4094
<member_range>: 1 to 26
<untag_range>: 0 to 26
Example:
PSES-2126C(VLAN)# set tag-group 2 VLAN-2 2-5,6,15-13 0
show config
Syntax:
