5. Installation instruction and calibration
Indoor installation: As shown in the
12.
picture, place the product so that the blue
line on the monitor is placed at the point
where the virtual red lines cross and fix it
with the angle adjusting bolt.
Horizont
al Line
14. After step 12, drive the car outside the
building and wait for about 5 minutes until
GPS reception is completed. Then, a voice
message explains that GPS reception has
been completed. After step 13, just wait at
the spot for GPS reception. When the GPS
reception is completed, drive the car to
calibrate the product.
13. Outdoor installation: First park the car in
an even, open place with no big obstacles
such as tall buildings. As shown in the
picture, place the product so that the blue
line on the monitor is placed on the
horizontal line (the point where the virtual
red lines cross) and fix it with the angle
adjusting bolt.
Artificial
Line
15. Drive for at least one minute over 30
km/h on a straight road with clear, continuous
lines (regardless dashed or not) on it, then a
voice message will say ―The Lane Departure
Warning System has been calibrated.‖ After
the message, all functions will operate
normally.
While waiting for the GPS reception, set the
car type. For details, refer to page 10 in this
manual. Also set volume, TTC, working speed,
etc.
Horizontal
Line
14
