Programmable 2 Channel High Performance Power Supply HMP2020
Programmable 3 Channel High Performance Power Supply HMP2030
All data valid at 23 °C after 30 minute warm-up
Outputs
Advanced parallel and series operation: simultaneously switch on/off of
active channels via 'Output' button, common voltage- and current control
using tracking mode (individual channel linking), individual mapping of
channels which shall be affected by FuseLink overcurrent protection
(switch-off), all channels galvanically isolated and independant from pro-
tective earth
HMP2020 1 x 0...32V/ 0...10A 0...5.5V/ 0...5A
HMP2030 2 x 0...32V/ 0...5A
Output terminals: 4mm safety sockets frontside
Screw-type terminal rear side
(4 units per channel)
Output power:
HMP2020 / HMP2030 188W max.
Compensation of lead
resistances (Sense): 1V
Overvoltage / overcurrent
protection (OVP / OCP): Adjustable for each channel
Electronic fuse: Adjustable for each channel,
combinable via FuseLink
Response time: ‹ 10ms
32V channels
Output values:
HMP2020 1 x 0...32V/ 0...10A, (5A at 32V)
HMP2030 2 x 0...32V/ 0...5A, (2.5A at 32V)
Resolution:
Voltage 1mV
‹ 1A: 0.1mA; ≥ 1A: 1mA
Current HMP2030
‹ 1A: 0.2mA; ≥ 1A: 1mA
Current HMP2020
Setting accuracy:
Voltage ‹ 0.05% + 5mV (typ. ±2mV)
Current HMP2030 ‹ 0.1% + 5mA (typ. ±0.5mA at I ‹ 500mA)
Current HMP2020 ‹ 0.1% + 5mA (typ. ±1mA at I ‹ 500mA)
Measurement accuracy:
Voltage ‹ 0.05% + 2mV
Current HMP2030 ‹ 500mA: ‹ 0.05% + 0.5mA, typ. ±0.2mA
≥ 500mA: ‹ 0.05% + 2mA, typ. ±1mA
Current HMP2030
Current HMP2020 ‹ 500mA: ‹ 0.05% + 0.5mA, typ. ±0.5mA
≥ 500mA: ‹ 0.05% + 2mA, typ. ±2mA
Current HMP2020
Residual ripple (3Hz...100kHz):
Voltage ‹ 150μV
Current ‹ 1mA
Stabilisation at load
change (10...90%):
Voltage ‹ 0.01% + 2mV
Current ‹ 0.01% + 250μA
Stabilisation at line voltage
variation (±10%):
Voltage ‹ 0.01% + 2mV
Current ‹ 0.01% + 250μA
Entire load regulation:
(at 10%...90% load peak, ‹ 50μs
balance time to match
within 10mV U )
nom.
5.5V channel
Output values:
HMP2020 / HMP2030 1 x 0...5.5V/ 0...5A
Resolution:
Voltage 1mV
‹ 1A: 0.1mA; ≥ 1A: 1mA
Current
Setting accuracy:
Voltage ‹ 0.05% + 5mV (typ. ±2mV)
Current ‹ 0.1% + 5mA (typ. ±0.5mA at I ‹ 500mA)
Measurement accuracy:
Voltage ‹ 0.05% + 2mV
Current ‹ 500mA: ‹ 0.05% + 0.5mA; typ. ±0.2mA
≥ 500mA: ‹ 0.05% + 2mA, typ. ±1mA
0...5.5V/ 0...5A
rms
rms
Residual ripple (3Hz...100kHz):
Voltage ‹ 150μV
Current ‹ 1mA
Stabilisation at load
change (10%...90%):
Voltage ‹ 0.01% + 2mV
Current ‹ 0.01% + 250μA
Stabilisation at line voltage
variation (±10%):
Voltage ‹ 0.01% + 2mV
Current ‹ 0.01% + 250μA
Entire load regulation:
(at 10%...90% load peak, ‹ 50μs
balance time to match
within 10mV U )
Nenn
Arbitrary Function easyARB (32V and 5V channels)
Parameters of points: Voltage, current, time
Number of points: 128
Dwell time: 10ms ...100s
Repetition rate: Continuously or burst mode
with 1...255 changes
Trigger: Manually via keyboard or via Interface
Maximum ratings
Reverse voltage: 33V max.
Incorrectly polarized voltage: 0.4V max.
Max. permitted current in
case of reverse voltage: 5A max.
Voltage to earth: 150V max.
Miscellaneous
Temperature coefficient / °C:
Voltage 0.01% + 2mV
Current 0.02% + 3mA
Display:
HMP2020 / HMP2030 240 x 64 Pixel LCD (full grafical)
Memory: Non volatile memory for 3 Arbitrary
functions and 10 device settings
Interface: Dual-Interface USB / RS-232 (HO720)
Process time: ‹ 50ms
Protection class: Safety class I (EN61010-1)
Power supply: 115 / 230V ± 10%; 50 / 60Hz, CAT II
Mains fuse: Microfuse 5 x 20mm slow blow
HMP2020 / HMP2030 115V: 2 x 6A
230V: 2 x 3.15A
Power consumption:
HMP2020 / HMP2030 350VA max.
Operating temperature: +5°C...+40°C
Storage temperature: -20°C...+70°C
Max. rel. humidity: 5%...80% (non condensing)
Dimensions (W x H x D):
HMP2020 / HMP2030 285 x 75x 365mm
Weight:
HMP2020 / HMP2030 8,5kg
Accessories supplied: Line cord, Operating manual,
Dual-Interface USB/RS-232 (HO720), CD
Optional accessories:
HO730 Dual-Interface Ethernet/USB
HO740 Interface IEEE-488 (GPIB), galvanically isolated
HZ10S 5 x silicone test lead (measurement connection in black)
HZ10R 5 x silicone test lead (measurement connection in red)
HZ42 2RU 19'' Rackmount Kit (HMP2020, HMP2030)
S p e c i f i c a t i o n s
rms
rms
Subject to change without notice
