Sawdust Vacuuming
The dust produced while working
is injurious to health. Remove
the dust and shavings by vacu-
uming and wear a protective
dust-proof mask.
Vacuuming
prevents it from accumutating
and causing a high dust concen-
tration of the air brealned in and
facilitates disposing of the dust/
sawdust.
The machine can be plugged directly into the re-
ceptacle of a Bosch general-purpose vac with re-
mote starting control. The vac starts automatically
when the Rotocut is switched on.
The vacuum cleaner must be suitable for the ma-
terial to be worked.
When vacuuming dry dust that is especially detri-
mental to health or carcinogenic, use a special
vacuum cleaner.
Bosch offers suitable vacuum cleaners for all ma-
terials to be worked.
For vacuuming, the 19 mm Ø suction hose
(1 610 793 002 or 2 600 793 009 - see accesso-
ries) can be connected directly to extractor con-
nection 8. For vertical surfaces, hold the machine
such that the suction hose is directed downwards.
When working with wood for a longer period and
during commercial treatment of materials that
produce dust that is detrimental to health, the ma-
chine is to be connected to a suitable external
dust extraction device.
Remove the spring washer
The housing may only be opened by au-
thorised qualified personnel!
Before any work on the machine itself, pull
the mains plug.
To open the housing, remove spring washer 21.
the dust/sawdust
Lever off the spring washer 21 using a screw-
driver.
Mounting/Dismounting the
Extractor Connection
Mounting:
Push the extractor connection 8 with the open slit
pointing to the knurled screw 6 onto the base
plate 7 until it is heard to notch.
Dismounting:
Ease the extractor connection 8 open a little at
the open slit and pull it off the base plate 7.
Before any work on the machine itself, pull
the mains plug.
6
21
7 8
