Apply the machine to the workpiece only when
switched on.
Always switch off the machine and allow to
come to a stop before placing it down.
Bosch is only able to ensure perfect functioning
of the machine if the original accessories in-
tended for it are used.
Intended Use
The unit is designed to cut gypsum, wood, plex-
iglass, plastics and soft wall tiles.
Changing the Tool
Before any work on the machine itself, pull
the mains plug.
A Press the spindle lock button 3 and turn the
union nut 4 until the spindle lock button notches.
Unscrew the union nut 4 using the open-end
spanner (SW 16) 2.
Insert the corresponding collet chuck 5 in the un-
ion nut 4, mount the union nut 4 and screw it on
tightly by hand through approx. 5 turns.
B Push in the cutting tool, leaving 3 mm of the
tool shaft still visible.
Press the spindle lock button 3 and tighten the
union nut 4 firmly using the open-end spanner
(SW 16) 2.
The shaft diameter of the cutting tool must
agree with the stipulated diameter of the tool
carrier.
The cutting tools used must be approved for
the highest speed for this machine type.
English - 2
Dismounting/Mounting/Setting
the Adjustable Base Plate
Only change or adjust the base plate 7
once the cutting tool has been removed.
Dismounting:
C Turn the base plate 7 anti-clockwise I until it is
felt to stop, and pull off.
Mounting:
C Push the base plate 7 with the hollow 12 over
the metal projection 13 and turn anti-clockwise II
until the base plate 7 with the projection is clearly
heard to notch in the hollow. Do not turn beyond
this projection.
Adjusting the Cutting Depth:
D Loosen the knurled screw 6. Adjust the base
plate 7 such that the cutting tool projects at least
6 mm from the material to be cut.
Tighten the knurled screw 6 firmly.
Initial Operation
Check for correct mains voltage: The voltage
of the power source must agree with the voltage
specified on the nameplate of the machine.
Equipment marked with 230 V can also be con-
nected to 220 V.
Machines marked 100 V can also be connected
to 115 V.
Switching on: Push out On/Off switch 9.
Switching off: Push the On/Off switch 9 to the
OFF position.
