Operating Elements And Connections - EuroLite DMX LED EASY Bedienungsanleitung

No. Element
1 Rotary controls for color selection (spot 1-4)
2 Dimmer fader spot 1-4
3 Case/Bank (12 settings)
4 Preset/User bank select
5 Scene select (12 settings)
6 Save/Delete
7 Master Dimmer
8 Chaser speed control
9 Fade time control
10 Strobe speed control
11 Blackout (standby, all LEDs off)

OPERATING ELEMENTS AND CONNECTIONS

No. Element
12 Push button Tap/Tempo
13 Mode button: Auto
14 Mode button: Music (sound control)
15 Mode: Strobe
16 XLR DMX output
17 DMX mode Multi/Single
18 DMX channel settings
19 Internal mic / external audio select
20 RCA input external audio
21 Input ext. power adaptor
22 Power on/off
