Clearaudio Smart Matrix Professional Bedienungsanleitung Seite 9

Smart Matrix Professional
User manaul
Bedienungsanleitung
TIP: For very dirty records, we recommend allowing the platter to turn more than twice in
each direction and repeating with a second or even third cleaning and vacuum process.
Please note:
Select anti-clockwise rotation of the platter for vacumming and thereafter do not switch the
rotation during the vacuuming process.
6. Press the 'VACUUM' button to start the vacuum process and wait until the record surface is completely
dry. Press the VACUUM button again to stop the vacuum process at which point the vacuum arm will lift
automatically. Please don't lift up the vacuum arm before this otherwise a line of fluid may be left on the
record.
7. Switch the machine off using the POWER button.
8. Remove the record clamp. Flip over the record and repeat the cleaning process for the other side.
3.5 Cleaning fluid tank
Please empty the waste fluid tank after 30 – 40 cleaning procedures.
For cleaning the waste fluid tank, remove the upper cleaning arm and fill 250 ml warm water in the
cleaning fluid into the stainless steel tube.
To empty the tank: first remove the stopper from the fluid release tube (on the rear panel of the
Smart Matrix Professional
).
Place the tube in an appropriate vessel to capture the fluid as it is flows out. Be sure to securely replace
the stopper in the fluid release tube.
Pic. 9: Cleaning the waste fluid tank
Please note:
If you take the machine into operation again, the drain tube must always be closed by the
stopper, so that the vacuum pump can generate the required vacuum for suction. Only
through this we can guarantee a lasting and full function of your cleaning maschine.
The drain tube is fixed with screws to prevent to push it back into the machine or to pull it out
too far.
© clearaudio electronic GmbH 2017 Page / Seite 9
