2.1.6 Power-up again after power failure:
If the duration of continuous power supply reaches 1 hour and the ballast is powered up again within
5 hours after a power failure, the ballast will continue operating according to the existing settings of
the Program and Start Time/Stop Time. If the above conditions cannot be met, only the program is not
changed, and you need to set the Start Time/Stop Time again. Meanwhile, the power-up time will be
set as the new Start Time, and this will affect the Stop Time accordingly. The RESET indicator will flash to
remind you of this change. When the Start Time is reset via the ballast or the remote control, the RESET
indicator will turn off immediately.
Notes:
- When the ballast operates in the Timer mode in the non-setting state, the panel screen displays the
target power and the countdown time alternately.
- The countdown time refers to the remaining time from the current status to the target status. For
example, if the Program shows 1806, the Start Time shows 13:00, and the current time is 21:20, that
means that the ON state has lasted for 8 hours and 20 minutes and the remaining time is 9 hours
and 40 minutes, so the countdown time displayed will show 9:40.
- If the ON indicator is ON, the countdown time refers to the remaining time before the HID lamp is
turned off automatically. If the ON indicator is OFF, the countdown time refers to the remaining
time before the HID lamp is turned on automatically.
2.2 Select the Bypass mode
2.2.1 Application:
When used with an external controller or timer, the ballast is the same as a regular electronic ballast
with no imbedded timer.
2.2.2 Enabling method:
Set the Program in the Bypass mode.
2.2.2 Enabling method:
Set the Program in the Bypass mode.
2.2.3 Reception of ON/OFF commands:
The HID lamp is turned on/off immediately.
2.2.4 Power-up again after power failure:
The ballast lamp keeps ON.
Notes:
- When the ballast operates in the Bypass mode in the non-setting state, the panel screen displays
the target power and "ByPA" alternately.
- It is strongly recommended to set the ballast in the Bypass mode when the ballast is controlled by
the external controller or timer. The Timer mode can still be set, but the Timer control of the ballast
may be subject to conflict with the external power supply control equipment.
