GIB Lighting LXG TIMER Benutzerhandbuch Seite 14

Thank you for purchasing this product. The ballast can be defi ned to work in two modes via a simple
setting. Timer mode: ballast with timing control function. Bypass mode: regular ballast with no timing
control function.
1. Introduction
1.1 Operating parameters of the electronic ballast
Input voltage range:
Rated input current:
Time for igniting after power on:
Minimum timing interval:
Working temperature:
1.2 Operating parameters of the remote control
Dry battery:
Complete standby current:
Working temperature:
Infrared transmission carrier frequency:
Maximum distance:
Clock mode:
1.3 Electronic ballast
Panel
180Vac-265Vac
2.8A@240Vac
≤15s
1min
-20°C to + 50°C (-4°F to +122°F)
AAA x 2, DC3V
<8uA
0°C to + 50°C (+32°F to +122°F)
38KHz
24feet
24-hours
Function Icons
Display Panel
LED
Buttons
Adjusting Knob
EN
