Notes:
- When the remote control is not available, you can select the Start Time and Stop Time of each day
by operating the ballast.
- When the ballast receives the latest Program or Start Time, it will run the latest Start Time and
Stop Time.
- The Start Time can be set as ST00 via the ballast or the remote control, which indicates that the
current time is defined as the Start Time.
- The Start Time can be set as ST-- via the ballast or the remote control, which indicates that the
existing - Start Time will not be changed. If the Program is changed, only the Stop Time changes.
2.1.4 Sun Function:
This can be used only in the Timer mode and works within the Start Time defined by the first two digits
of the Program parameter. When the HID lamp is turned on within the first 10% of ON time, the output
power gradually increases from 250W to the target power. The target power will be maintained in the
following 80% of ON time. In the last 10% of ON time, the output power will gradually decrease to 250W,
and then the HID lamp will be turned off. The Sun Function simulates three phases from sunrise to sun-
set. Meanwhile, the ON indicator of the ballast will flash in the Sunrise and Sunset phase and keeps ON in
the maintenance phase to indicate that the target power is being outputted. When the Sun Function is
enabled, the target power can be changed at any time, and the ballast will automatically recalculate and
adjust the output power according to the current phase.
2.1.5 Reception of ON/OFF commands during operation of the Program:
Refer to Tables 5 and 6.
Table 5: Reception of ON Command During Operation of Program
Program
Operation Phase
Lamp ON Ignore the command.
Turn on the HID lamp immediately; keep the ballast latest program to run the
Lamp OFF
Start Time and Stop Time.
Table 6: Reception of OFF Command During Operation of Program
Program
Operation Phase
Turn off the HID lamp immediately; keep the ballast latest program to run the
Lamp ON
Stop Time and Start Time.
Lamp OFF Ignore the command.
Ballast Reaction
Ballast Reaction
Start Time & Stop
Time
No change
No change
Start Time & Stop
Time
No change
No change
