Dimensions (mm)
Models for standard applications (PKE 51x und 52x)
NETZ
POWER
ENTER
11.5"
12.2"
Please indicate with order
Please extract the part number for the cooler fulfilling your requirements from the type code below.
Please note : Each gas path should be equipped with a peristaltic pump or an automatic condensate drain. A peristaltic
pump cannot be installed at the factory in versions with 24 V mains supply.
Part-no.
4 4 6
5 1 1
5 2 1
Part-no.
4 4 6
5 1 2
5 2 2
1
1)
Heat exchangers MTS, MTG and MTV cannot be drained by automatic drainers
Accessories
Part No. Description
45 100 08 Automatic condensate drain type AK 5.2
44 100 05 Glass vessel GL 1
91 240 300 27 Spare tube for peristaltic pump, right angle terminals
DA 440012
10/2013
Page 4/4
ALARM-
AUSGANG
ALARM-
OUTPUT
A000138A
0 0 0
Types with one Heat Exchanger
PKE 511: Standard ambient temperature 40 °C
PKE 521: Standard ambient temperature 50 °C
Material Heat Exchanger / Version
1 Stainless steel / (PTS or PTS-I)
2 Glass / (PTG)
3 PVDF / (PTV or PTV-I)
Power Supply
1 115 V metric fittings
230 V metric fittings
2
3 115 V US fittings
4 230 V US fittings
5 24 V DC metric fittings
6 24 V DC US fittings
Condensate Discharge
0 None
1 One peristaltic pump
0 0 0
Types with two Heat Exchangers
PKE 512: Standard ambient temperature 40 °C
PKE 522: Standard ambient temperature 50 °C
Material Heat Exchanger / Version
Stainless steel / (MTS or MTS-I)
Glass / (MTG)
2
PVDF / (MTV or MTV-I)
3
Power Supply
1 115 V metric fittings
2 230 V metric fittings
3 115 V US fittings
4 230 V US fittings
5 24 V DC metric fittings
6 24 V DC US fittings
Condensate Discharge (only 115 V / 230 V)
0 None
Two peristaltic pumps
2
5.51"
Air
In
5.91"
5.12"
Air
In
Air
Out
Air
Out
1)
We reserve the right to amend specification
