1.4 Components

1 Motor-driven external unit
2 Offset satellite dish with a diameter of 65-80 cm
3 Universal LNB
4 Assembly plate
5 User control panel, display version (only plus models)
6 Watertight box for the inside passage of the cables
7 Wiring
8 Assembly and use manual
9 Control box for external unit
10 Control panel – box rj45 connection cable
11 Box power connector
12 LED version user control panel (for the basic version)
