BVC Junior Bedienungsanleitung Seite 21

O
PERATING AND
Low-voltage cable - connection sketch
24 V of control lines to the individual suction doses are to be switched into row. Grinding through from first to the last
suction box needs fewer control cables. It is likewise possible to attach each suction box with a separate cable and to
bundle these at the central vacuum cleaner. Shifting of the control line (e.g. in a troughing), separated from the suction
pipe, with other 230 V or high voltage power cables can lead to malfunctions of the central vacuum cleaner
The safety pipe elbow must
be installed behind every
socket.
24 volt control lead
Descending and ascending
pipes must not be in
alignment, but should
be stagered.
M
AINTENANCE
VAC PAN
with foot switch
21
I M
NSTRUCTION
correct
incorrect
© 2011 BVC/EBS, Schweinfurt
ANUAL
to the vacuum
cleaner
to the vacuum
cleaner
