Display selection in "Set CIP ranges" mode

8.6.1

Ranges selection menu

Fig. 8.44
Range No.:
CIP 1
CIP 2
CIP 3
CIP 4
The CIP ranges are externally selected with two 24 V AC/DC signals
Range No.:
8.6.2

Set CIP range 1-4

8.6.2.1 Conductivity measuring range

Fig. 8.45
417101109_LMIT08.doc
Measuring range
0...2 mS/cm
0...5 Gew. % P3-mip liquide
0...5 Gew. % P3-horolith liquide
----------
CIP 1
CIP 2
CIP 3
CIP 4
Configuration example:
TKα
2,30%K 0...20 mA = 0...1 mS/cm
---------- 0...20 mA = 0...2 weight / %
---------- 0...20 mA = 0...1 weight / %
---------- ----------
Input "A"
0 V
24 V
0 V
24 V
- 76 -
Current output
Input "B"
0 V
0 V
24 V
24 V
Rev. 3-01.10
