Component explanation

3 Component explanation
3.1

Keys

Fig. 1: Component explanation
Number Key
1 SET
2 ESC
3 RESET
4 LOG/▲
5 MIN/MAX▼
1 + 4 + 5 Set + ▲ + ▼
(Press simultane-
ously)
36
Function
Enter setup mode
Save and finish settings
Exit setup mode
Exit data logging mode
Terminate datalogging
Terminate calibration
Clear MAX/MIN records
Start data logging
Select mode
Increase value in setup mode
Activate MIN/MAX function
Select mode
Decrease value in setup mode
CO - calibration
