Asus Maximus III Formula Handbuch Seite 86

DRAM REF Cycle Time [Auto]
Konfigurationsoptionen: [Auto] [30 DRAM Clock] [36 DRAM Clock]
[48 DRAM Clock] [60 DRAM Clock] [72 DRAM Clock] [82 DRAM Clock]
[88 DRAM Clock] [90 DRAM Clock] [100 DRAM Clock] [110 DRAM Clock]
DRAM WRITE Recovery Time [Auto]
Konfigurationsoptionen: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
DRAM READ to PRE Time [Auto]
Konfigurationsoptionen: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
DRAM FOUR ACT WIN Time [Auto]
Konfigurationsoptionen: [Auto] [1 DRAM Clock] – [63 DRAM Clock]
2nd Information: 1N-49-52
Die Werte beziehen sich aus den Einstellungen für folgende Unterelemente:
DRAM Timing Mode [Auto]
Konfigurationsoptionen: [Auto] [1N] [2N] [3N]
DRAM Round Trip Latency on CHA/B [Auto]
[Auto] [Advance 15 Clock]–[Advance 1 Clock] [Normal] [Delay 1 Clock]
[Delay 15 Clock]
3rd Information: 6-6-13-9-9-9-7-6-4-7-7-4
Die Werte beziehen sich aus den Einstellungen für folgende Unterelemente:
DRAM WRITE to READ Delay(DD) [Auto]
Konfigurationsoptionen: [Auto] [1 DRAM Clock] – [8 DRAM Clock]
DRAM WRITE to READ Delay(DR) [Auto]
Konfigurationsoptionen: [Auto] [1 DRAM Clock] – [8 DRAM Clock]
DRAM WRITE to READ Delay(SR) [Auto]
Konfigurationsoptionen: [Auto] [10 DRAM Clock] – [22 DRAM Clock]
DRAM READ to WRITE Delay(DD) [Auto]
Konfigurationsoptionen: [Auto] [2 DRAM Clock] – [14 DRAM Clock]
DRAM READ to WRITE Delay(DR) [Auto]
Konfigurationsoptionen: [Auto] [2 DRAM Clock] – [14 DRAM Clock]
DRAM READ to WRITE Delay(SR) [Auto]
Konfigurationsoptionen: [Auto] [2 DRAM Clock] – [14 DRAM Clock]
DRAM READ to READ Delay(DD) [Auto]
Konfigurationsoptionen: [Auto] [2 DRAM Clock] – [9 DRAM Clock]
3-12 Kapitel 3: BIOS-Setup
