Quick reference
31.4005.02 WeatherHub weather station
Download App
Download the WeatherHub app from the „Apple App Store" or „Google Play Store".
Connect the Gateway
Connect the gateway to the power supply using the supplied AC adapter. Connect the included LAN cable with the gateway and your
router. After about 10 seconds, the gateway is in operation. The LED will turn static green. If no DHCP server is available in your network,
you can configure the gateway in the app under the point "Settings" manually. If the green LED on the gateway is not permanently lit,
please check if the gateway is properly connected to the power plug and the router and if it is turned on and is connected to the internet.
(More information can be found in the app under „Info").
Important: The gateway should always be put into operation before starting the sensors!
Sensor set up
Set up the transmitter as descripted in the manual of the specific sensor and look for a suitable location.
Add sensor
Open the app, dashboard is displayed. The sensor „Hannover" is only for testing purposes and may be deleted. Tap „Add new sensor"
and scan the QR code on the sensor. Then set a name for the sensor. To set a name, select the transmitter and then tap on the left area
of the pencil icon in the upper right. Repeat this process for the remaining sensors.
Configuration of the weather station
Using simultaneously the T / H sensor (30.3303.02), the rain sensor (30.3306.02) and the wind sensor (30.3307.02) it is possible to
show all readings in one combined weather station display and to activate PRO functions (graphic display, max-min. display, data export).
1
Select „add & Configure" in
the setting options.
Read measurements
Now you can read the measurements and overviews on your mobile phone.
Troubleshooting
When no sensor readings are displayed in the app, first check if the green LED on the gateway is permanently lit.
(See "Connect the gateway")
If the gateway works properly, we recommend to the following steps:
•
Check if the batteries in the sensor are inserted with the correct polarity.
•
Restart the sensor by removing the batteries for a minute and reinserting.
•
Check if your phone is connected to the internet.
•
Decrease the distance between sensor and gateway. The signal may be weakened by thick
walls and ceilings.
•
More information can be found in the app under „Info".
Specifications (Gateway)
Power supply:
Input power adapter:
Output power adapter:
Network connection:
More specification please find in the manuals of the sensors.
Waste disposav
This product has been manufactured using high-grade materials and components which can be recycled
and reused.
Do not dispose of batteries or rechargeable batteries in the household waste!
2
As a consumer, you are legally required to take them to your retail store or to appropriate
collection sites according to national or local regulations in order to protect the environment.
The symbols for the heavy metals contained are: Cd=cadmium, Hg=mercury, Pb=lead
Here you can specify
a name.
This instrument is labelled in accordance with the EU Waste Electrical and Electronic Equipment
Directive (WEEE). Please do not dispose of this product with other household waste. The user is
obligated to take end-of-life devices to a designated collection point for the disposal of electrical
and electronic equipment, in order to ensure environmentally-compatible disposal.
EU Declaration of conformity
Hereby, TFA Dostmann declares that the radio equipment type 31.4005.02 is in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following internet address: www.tfa-dostmann.de, E-Mail: info@tfa-dostmann.de
TFA Dostmann GmbH & Co.KG, Zum Ottersberg 12, D-97877 Wertheim, Germany
3
No part of this manual may be reproduced without written consent of TFA Dostmann.
The technical data are correct at the time of going to print and may change without prior notice.
Press and complete
the configuration.
More information and detailed instructions can be found in the app at "Info" or on
www.tfa-dostmann.de/weatherhub.
Power adapter
230 V~/ 50 Hz (35 mA)
20 V~ (100 mA)
LAN (RJ45)
05/2017
