ASRock Front USB 3.1 Panel (for Z170 Extreme6+ only)
Speciications
• 75mm (W) x 42.8mm (H) x 148mm (L)
Dimension
• ASMedia ASM1142 Controller
Controller
• 1 x USB 3.1 Type-A Port (10 Gb/s) (Supports ESD Protection
* For charging Type-A USB devices, we suggest using the Type-A
connectors on your motherboard.
• 1 x USB 3.1 Type-C Port (10 Gb/s) (Supports ESD Protection

Front Panel

I/O
* his port supports power outputs up to 5V/3A. For charging Type-C
USB devices, the device should support Type-C standards to adjust the
current because it will be diferent in Power On state (3 Amp) and Sleep
state (1 Amp).
* Some Type-C USB devices may only be charged by its own adapter.
• 1 x SATA Express 10 Gb/s Connector
Connector
• 1 x USB Power Connector
• Microsot® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit
OS
* It is recommended to install the ASRock Front USB 3.1 Panel into the drive bay of
your chassis before connecting other USB devices.
(ASRock Full Spike Protection))
(ASRock Full Spike Protection))
Z170 Extreme6+ / Z170 Extreme6
