Sensor current ............................................. Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire)
Sensor error detection ................................ Yes
Short circuit detection ................................. < 15 Ω
Bipolar current input:
Measurement range .................................... -100...+100 mA
Input resistance ........................................... 10 Ω + PTC < 20 Ω
Cable breakage detection (4...20 mA) ........ < 0,3 mA
Bipolar mV input:
Measurement range .................................... -800...+800 mV
Min. measurement range (span) ................. 2.5 mV
Input resistance ........................................... 10 MΩ
Short circuit detection ................................. < 3 mV
TC input:
Min.
Type
value
B
+400°C
+1820°C
E
-100°C
+1000°C
J
-100°C
+1200°C
K
-180°C
+1372°C
L
-200°C
+900°C
N
-180°C
+1300°C
R
-50°C
+1760°C
S
-50°C
+1760°C
T
-200°C
+400°C
U
-200°C
+600°C
W3
0°C
+2300°C
W5
0°C
+2300°C
Ext. CJC
-40°C
+135°C
Cold junction compensation (CJC) ............. < ±0.5 °C
Sensor error detection ................................ Yes
Sensor error current:
when detecting ....................................... nom. 2 µA
else .......................................................... 0 µA
Short circuit detection ................................. < 3 mV
Output:
®
connection:
PROFIBUS
PA
®
protocol .............................. Profile A&B, ver. 3.0
PROFIBUS
PA
®
protocol standard ............... EN 50170 vol. 2
PROFIBUS
PA
®
address (at delivery) ........... 126
PROFIBUS
PA
®
PROFIBUS
PA
function blocks ................... 2 analogue
24
24
. < 0.002 Ω / Ω
Max.
value
Standard
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
ASTM E988-90
ASTM E988-90
IEC60751
TM
F
Fieldbus connection:
OUNDATION
TM
F
Fieldbus protocol ................. FF protocol
OUNDATION
F
TM
Fieldbus protocol standard .. FF design specifications
OUNDATION
TM
F
Fieldbus capability ............... LAS or Basic
OUNDATION
TM
F
Fieldbus version ................... ITK 4.6
OUNDATION
TM
F
Fieldbus function blocks ...... 2 analogue and 1 PID
OUNDATION
EEx / I.S. approval:
Instructions for safe installation:
Installation Drawing No. .............................. 6350QE02
EEx / I.S. approval - 6350A:
KEMA 03ATEX1013 X ..................................
ATEX, applicable in zone ............................. 2
FM and CSA, applicable in ......................... Class I, Div. 2, Group A, B, C, D
EEx / I.S. data:
6350A
Zone 2, EEx nA [nL] IIC
Division 2,
nonincendive
No
Unit
barrier
U i
32 VDC
T1...T4
T
< 85°C
amb.
T5
T
< 75°C
amb.
T6
T
< 60°C
amb.
Sensor input, terminal 41, 42, 43 og 44 and (51, 52, 53 54):
U
................................................................ : 5.7 VDC
o
I
................................................................. : 8.4 mA
o
P
................................................................ : 12 mW
o
L
................................................................ : 200 mH
o
C
................................................................ : 40 µF
o
EEx / I.S. approval - 6350B:
KEMA 03ATEX1012 .....................................
II 3 G
EEx nA [L] IIC T4...T6
Class I, Zone 2, Group IIC
II 1 GD or II 2 (1) GD
EEx ia IIC T4...T6 or
EEx ib [ia] IIC T4...T6
FISCO
25
25
