CHARACTERISTICS
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
2.1 1 Upper Section
2.2 1 Lower Section
8 1 Directional Air Outlet grille
9 1 Flange
16 1 Filter cover
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Brackets
11 6 Wall Plugs
11a 2 Wall Plugs SB 12/10
12a 6 Screws 4,2 x 44,4
12c 10 Screws 2,9 x 6,5
12d 2 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
EN
Components
Filters
2.1
2.2
9
12a
7.2.1 11
12c
12d
8
12c
16
11a
1
11
12a
1 14
