Dexxo Compact RTS
7 - PARAMETER SETTING AND
OPERATING OPTIONS

7.1 General parameter setting diagram - Fig.24

7.2 Meaning of different parameters
Programming example: Adjusting the long slow zone (Fig. 25)
Indicator
Obstacle detection sensitivity
light A
Indicator
1 : very low sensitivity
light B
2 : slightly sensitive
3 : standard
4 : very sensitive
If this parameter is changed, the installer must check that the obstacle
detection complies with appendix A of standard EN 12 453.
Failure to follow this instruction may result in serious injury, e.g. due to
crushing by the gate.
Indicator
Docking speed when closing
light A
Indicator
1 : no reduction in speed
light B
2 : short slowing
3 : long reduction in speed
Comments 1: no reduction in speed at the end of closing.
2: the speed is reduced during the last 20 centimetres.
3: the speed is reduced during the last 50 centimetres.
If this parameter is changed, the installer must check that the obstacle
detection complies with appendix A of standard EN 12 453.
Failure to follow this instruction may result in serious injury, e.g. due to
crushing by the gate.
Indicator
Auto-programming mode
light A
Indicator
2 : waiting for auto-programming
light B
0 : self-learning is complete
Indicator
Locking the parameters menu
light A
Indicator
0 : the parameters menu is locked
light B
If button B is pressed accidentally, move on to step 10 to unlock the
parameters menu
Indicator
light A
Indicator
1 : power supply
light B
2 : solar
Memorising the remote control for operation in "Partial opening"
mode (Fig. 26)
The remote controls supplied in the kit have already been memorised.
It is possible to memorise up to 32 control channels.
If this procedure is carried out using a channel which has already been
memorised, this channel will be cleared.
Memorising a Telis type remote control or similar (Fig. 27)
Copyright © 2015 Somfy SAS. All rights reserved
WARNING
WARNING
Power supply

8 - SPECIFIC OPERATION

See the user booklet.
9 - CLEARING THE REMOTE CONTROLS
AND ALL SETTINGS

9.1 Deleting remote controls - Fig. 28

Press button "B" until the light flashes (7 sec.).
Causes all memorised remote controls to be cleared.

9.2 Reinitialising all settings - Fig. 29

[1]. Press button "A" 3 times to access the auto-programming parameter.
[2]. Press button "B" to enter auto-programming mode. Indicator light B
flashes twice continuously.
[3]. Control the motor with button "A" so that the transmission shuttle is
engaged on the carriage and brings the door to the closed position.
[4]. Press "B" to launch the auto-programming cycle.
The door performs a complete Opening-Closing cycle.
- If the auto-programming is correct, indicator light B goes out.
- If the auto-programming cycle was not successful, indicator light B
flashes twice continuously.
10 - UNLOCKING THE PARAMETERS MENU
FIG. 30
Note: If the parameters menu is locked and no memorised remote control
is available, it will be necessary to memorise a remote control first (fig.
26 or fig. 27).
[1]. Press and hold button A on the DEXXO COMPACT.
[2]. Without releasing button A, press a button on a remote control which is
already memorised. The light on the DEXXO COMPACT comes on briefly
to indicate that unlocking has taken place.
[3]. Release button A.
Once the work being carried out by the professional is complete, the
parameters menu must always be locked to ensure the safety of users.
Failure to follow this instruction may result in serious injury, e.g. due to
crushing by the gate.

11 - REFITTING THE COVER FLAP - FIG. 31

Fit the cover flap.
WARNING
