E - Cooking zone display
F - Display Timer
G - Indicator of dual active cooking zone
• Switching the cooking top on:
Press A key to switch the top on.
All the displays relative to the cooking zones switch on in the
standby position.
The control unit remains active for 20 seconds.
If no cooking zone is selected within this time, the ccoking
top switches off automatically.
• Switching the cooking area on:
Select the area of cooking and pressing one of the E display.
Slide the slider to increase and B to decrease the power of
the cooking zone.
The power of the single cooking zone can be adjusted in
9 different positions, and will be displayed on the display
bright and with a number from "1 to 9". And with the display
to number from "1 to 9".
• Switching the double cooking area on:
- For activate this feature, select the plate with the double
cooking zone and adjust the power with the slider B.
- When the corresponding led will start flashing, select the
key A (for about 5 seconds) and the G led light up.
- Two BEEP conferm the activation this feature.
- Select the key A (for about 5 seconds) and two BEEP
conferm the enable.
• Residual Heat:
If the temperature of the cooking zone is still high (over
50°) after it has been switched off, the relative display will
indicate the
symbol (residual heat). The symbol will only
switch off when the burn risk in no longer present.
• Pot detection:
if the symbol
should appear on one of the cooking area
displays, it means that:
1) The recipient being used is not suitable for induction
cooking.
2) The diameter of the recipient used is inferior to that
allowed by the appliance.
3) No recipient is present.
• Timer:
This feature allows you to set the time (from 1 to 99 minutes)
to automatically turn off the cooking zone selected. Activate
a cooking area and adjust the power. Enable the timer on the
display by pressing F. The display will show the symbol
and the LED on the selected zone set on one corner of the F
display will flash. Scroll bar slider B to set the desired value
(eg 3 min.). Press F on the display which will display the scroll
bar slider back and set the desired value (eg, 23min.) On the
display and confirm by pressing F. If you wish to confirm a
time less than 10min timer. (eg 3 min.) Confirm by pressing
twice on the display F. The timer will automatically turn off
the cooking area and you will hear a beep that can be turned
off by pressing any of the commands.
• Egg timer/reminder:
This feature allows you to set a reminder sound.
To access this feature none of the cooking areas shall be in
operation. Turn on the stove using the A button, activate
the timer by pressing the display area F and adjust any
time between 1 to 99 minutes as described in the previous
paragraph TIMER. After confirmation of the memorandum,
the LED will remain active on the A key and the display F
with the time previously set. At this point you can turn back
the hob with the A button and adjust the cooking zones.
When the timer expires you will hear a beep that can be
turned off by pressing any of the commands.
With the reminder you can not access the active timer.
• Pause:
When at least one cooking zone is operating it is possible
to momentaneously pause the appliance switching off the
heating elements by pressing the D key. When the pause
function is active the relative led is on. The pause may last
for 10 minutes. If the status is not terminated within this
time the appliance switches off. The pause function can be
deactivated by pressing the D key and within 10 seconds
any of the control keys. Previously programmed timers will
be stopped during the pause.
• Recall:
When the appliance has been switched off by mistake it is
possible to quickly recall the previously active settings by
pressing the on-off A key withing 6 seconds, then pressing
the D key within another 6 seconds. If the recall function
is available the relative led will be enlighted when the
appliance is swithcehd on again.
• Control panel lock:
It is possible to block the controls to prevent the risk
of unintentional modification of the settings (children,
cleaning etc.). Switch on the cook top with A key, and within
10 seconds, simultaneously press the display E in the lower
right corner and the C key, then press againn the display E
in the lower right corner. All displays E will show the symbol
. To temporarily unlock the commands and return to
action on the adjustments (eg, stop the cooking), you must
simultaneously press the dispaly E in the lower right corner
and press C key. When the Control lock is on, you can always
switch off the hob. In this case, the Control lock remains
active even at restart hob. To unlock the hob permanently,
press simultaneously the display E in the lower right corner
and the C key, then press the C key again. The hob will shut
off automatically.
• Switching the cooking area off:
To turn off a cooking zone, pressing the Display selections
E. Raids on the B slider bar to the left until you see on the
display
.
• Switching the cooking top off:
To turn off the cooking top entirely hold down the A key.
• Safety switch:
The appliance has a safety switch that automatically switch-
es off the cooking zones when they have been operating for
a certain amount of time at a given power level.
POWER LEVEL
OPERATING TIME LIMIT (hours)
1 - 2
6
3 - 4
5
5
4
6 - 7 - 8 - 9
1,5
DISPOSAL OF OLD HOUSEHOLD
- 10 -
3PCLIOBTS642
APPLIANCES
The European Directive 2002/96/EC on Waste Elec-
trical and Electronic Equipment (WEEE), requires
that old household appliances shall not be disposed
of in the standard urban solid waste stream. Old ap-
pliances shall be collected separately in order to optimize
the recovery and recycling of the materials they contain and
reduce the impact on human health and the environment.
The crossed-out dustbin symbol on the product reminds you
of your obligation regarding separated waste collection.
Consumers should contact their local public service or their
local dealer for more information on the correct disposal of
old household appliances.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY
FOR POSSIBLE DAMAGES CAUSED BY NOT ABIDING TO
THE ABOVE MENTIONED WARNINGS.
