DISMISSIONE DEGLI ELETTRODOMESTICI
La direttiva Europea 2002/96/CE sui rifiuti di appa-
recchiature elettriche ed elettroniche (RAEE), preve-
de che gli elettrodomestici non debbano essere
smaltiti nel normale flusso dei rifiuti solidi urbani. Gli
apparecchi dismessi devono essere raccolti separatamente
per ottimizzare il tasso di recupero e riciclaggio dei materiali
che li compongono ed impedire potenziali danni per la salu-
te e l'ambiente. Il simbolo del cestino barrato è riportato su
tutti i prodotti per ricordare gli obblighi di raccolta separata.
Per ulteriori informazioni, sulla corretta dismissione degli
elettrodomestici, i detentori potranno rivolgersi al servizio
pubblico preposto o ai rivenditori.
SI DECLINA OGNI RESPONSABILITÀ PER EVENTUALI
DANNI PROVOCATI DALLA INOSSERVANZA DELLE SUD-
DETTE AVVERTENZE.
- 8 -
3PCLIOBTS642
GENERAL INFORMATION
Carefully read this use and maintenance manual, where
important information about installation, use and mainte-
nance safety is provided. Keep this manual for future refer-
ence. Any installation operation (electric connections) shall
be performed by specialized personnel, in compliance with
all standards and regulations in force.
SAFETY WARNING
The use of flat-bottomed pots, with a diameter equal to
or slightly bigger than the heated area, is recommended.
(Fig.5). Do not use pots that have a rough base, in order to
prevent the hob thermal surface from being scratched. This
appliance is not intended for use by children or infirm peo-
ple without supervision.
IMPORTANT
- Avoid the overflow of liquids by reducing the heat sup-
ply when boiling or warming liquids.
- Do not leave any heating element switched on, if there
are no pots, or if the pots are empty.
- Once cooking is completed, turn the concerned heating
element off, by using the control shown below.
- This appliance is not intended for use by people (chil-
dren included) with limited physical, sensorial or mental
abilities, or lacking of experience and knowledge, unless
they are supervised or well instructed about the use of
the appliance, by a person who is responsible for their
safety.
- Children should be supervised to assure that they do
not play with the appliance.
- If the hob surface is cracked, turn the appliance off and
disconnect it from the electric network , so as to avoid
the possibility of electric shock.
INSTALLATION INSTRUCTIONS
These installation instructions are intended for a specialized
installer and are meant as guidelines for the hob installa-
tion, adjustment and maintenance, in compliance with any
regulations and standards in force. If a built-in oven or any
other appliance generating heat is to be mounted directly
under the vitro-ceramic hob, IT IS NECESSARY THAT SUCH
AN APPLIANCE (the oven) AND THE VITRO-CERAMIC HOB
ARE PROPERLY INSULATED. Failure to comply with this pre-
caution might result in the incorrect operation of the TOUCH
CONTROL system.
• Positioning:
This household appliance has been designed for built –in
installation onto a worktop, as shown in the figure (Fig.2).
Use sealing material along the whole perimeter - Fig.4 (Cut
dimensions- Fig.2). This operation is necessary in order to
prevent any liquid from entering inside the hob, being that
the flatness of the top, the glass and their coupling cannot
be assured. Fix the appliance on the worktop by using the 4
3PCLIOBTS642
ENGLISH
supports, taking the work top thickness into account (Fig.2).
If, after installation, the lower part of the appliance is acces-
sible from the lower part of the cabinet, it will be necessary
to mount a spacing panel at the distances given (Fig.3). If
the appliance is installed under an oven, this step will not be
necessary. The appliance is not intended to be operated by
an external timer or a separate remote control system.
• Electric connections (Fig.7):
Before carrying out any electric connections, please make
sure that:
- the ground electric cable is 2 cm. longer than the other ca-
bles;
- the electrical system meets any requirement mentioned in
the rating label found on the underside of the work top;
- the electrical system is equipped with an efficient ground-
ing system and compliant with any standards and law direc-
tives in force.
The grounding system is required by law.
In the case the appliance is not equipped with a power cord
and/or the related plug, please use a material suitable for the
power absorption value mentioned in the rating label and
for the operating temperature. If a direct connection to the
electric network is required, you need to use an omnipolar
power switch with a switch-contact gap of at least 3 mm,
suitable for the value mentioned in the label, and compliant
with the related standards in force (the yellow/green ground
connection shall not be interrupted by the change-over
switch).
Once the appliance installation is completed, the omnipolar
switch shall be easily accessible.
USE AND MAINTENANCE
• Maintenance (Fig.6):
Remove any food residue and grease drops from the cooking
surface, by using the special scraper provided on request.
Clean the heated area in the best way possible, using suita-
ble products and a paper towel, then rinse with water and
wipe away with a clean cloth.
Through the use of the special scraper (optional), prompt-
ly remove any pieces of aluminum foil and plastic material,
which might have accidentally melted, or sugar or food
remains, and/or remains of sugary foods, from the heated
surface. In this way, any possible damage to the surface is
prevented.
The use of abrasive sponges or irritating chemical cleaners,
such as sprays for ovens or cleaning agents is not allowed
under any circumstance.
• Use:
Use the touch control system in the corresponding position
according to individual cooking needs. Keep in mind that
the higher the number, the more heat is produced.
• Function (Fig.1):
A - ON/OFF key
A1 - Led ON/OFF key
B - Slider
C - Selection key dual cooking zone
D - Key Pause/Recall
D1 - Led Pause/Recall
- 9 -
