5. NEO with Filter Shaft

5.1 FI-1 filter shaft: basket filter for standard garden systems
5.2 FI-2 filter shaft: filter with siphon for standard domestic systems
The contents of the technical documentation are a component of the guarantee terms
Planning and installation regulations are to be followed, as well as the accident prevention regulations.
Premier Tech Aqua • Rewatec
www.premiertechaqua.de
Technical changes and rights reserved. No liability for misprints
®
25/28
A: Inflow DN 100
B: DN 100 supply pipe
C: DN 100 overflow
NEO HZU HV
1500 885 891
3000 1265 1270
5000 1328 1334
8000, 1498 1504
10000,
etc.
A: Inflow DN 100
B: DN 100 supply pipe
C: DN 100 overflow
NEO HZU HV
1500 885 891
3000 1265 1270
5000 1328 1334
8000, 1498 1504
10000,
etc.
NEO Flat tanks
DORW5001-21.09.2016
HAB
545
962
975
1150
HAB
835
1215
1278
1448
